Dahua AC Switching Power Supply - PFM320D-EN - DC12V 2.0A
Easy installation with indicator light; wide operating range -30°C to +70°C; full-load efficiency up to 100% at these temperatures.
Please Note
The website is currently being actively developed, you are welcome to place the order and in 99% of the cases your order will be processed as usual, but in some cases there may be a delay or the price may change. We will notify you if there are any issues.
Discontinued
This item was discontinued and currently is not available for order on our website. The item may become available soon. Please contact us if you need more information regarding the upcoming arrivals.
| Power Supplies - Type | 12V DC Adaptor |
|---|---|
| Power Supplies - Output Current | 2 A |
- Easy installation
- With indicator light working
- Support -30℃~+70℃ wide-range temperature operation, and the full load efficiency of the power supply can be up to 100% at these temperatures
- Accurate overcurrent, overvoltage protection
- Fully Meets ERP.COMMISSION REGULATION (EU)2019/1782 Requirement
Electrical Specification
- Rated input : AC100~240V, 50/60Hz, 0.6A
- Output : DC12V , 2A (+7%, -3%)
Protection/Environmental
- Protection : Surge protection, over temperature protection, over current, voltage load protection / ESD: EN61000-4-2 / +/- 4kV Contact; +/-8kV Air / Surge: EN61000-4-5 / Combination Wave: Common Mode ±4KV(12 ohms) / Differential Mode ±2kV(2 ohms)
- Working temperature : -30?~+70
- Working humidity :<95% RH
Physical Properties
- Weight : 170g
- Dimension(LxWxH) : 104 mm × 45 mm × 33 mm
- Installation : Plane installation
- Color : Black
- Input plug : 2-pin Euro plug
-
Outgoing Cord : AC wire: 50 cm (19.69"), DC wire: 80 cm (31.50")
Safety Standards
- Certification : PFM320D-EN/PFM320D-BS: / CE LVD(EN62368-1:2014+A11:2017) / CE EMC(EN55032:2015,EN61000-3-2:2014,EN61000-3-3:2013,EN55035:2017) / PFM320D-US: / UL-VI(UL60950-1) / FCC(FCC Part 15 Subpart B) / DOE(VI) / CEC(VI)
| Voltage | 12V |
| Ampers | 2A |
