Dahua IP 5.0MP 4.0mm Wifi PT Dome Dual Illumination - SD-P5AE-PV - Dahua IP 5.0MP 4.0mm Wifi PT Dome Dual Illumination
Outdoor 5MP WiFi PT Dome with dual illumination; active defense alarms, AI detection, auto tracking, two-way audio, and up to 256GB microSD storage.
Please Note
The website is currently being actively developed, you are welcome to place the order and in 99% of the cases your order will be processed as usual, but in some cases there may be a delay or the price may change. We will notify you if there are any issues.
Discontinued
This item was discontinued and currently is not available for order on our website. The item may become available soon. Please contact us if you need more information regarding the upcoming arrivals.
| IP Cameras - Form Factor | Dome |
|---|---|
| IP Cameras - Resolution | 5 MP |
| IP Cameras - Audio | Mic + Speaker (2-way) |
| IP Cameras - Storage | microSD |
- The Active Defense series of small PT cameras raises the bar on performance. After detecting an intrusion, it triggers sound and light alarms, and then instantly relays vital information on the intrusion to the mobile client, keeping you informed no matter where you are
- It supports two-way talk, allowing you to communicate with people in front of the camera in real time.It also can record full-color videos and information of key events using Smart Dual Illuminators, effectively reducing light pollution
- Connects with any Dahua NVR
Camera
- Image Sensor : 1/2.8" CMOS
- Pixel : 5 MP
- Max. Resolution : 2560 (H) × 1920(V)
- Electronic Shutter Speed : 1 s–1/100,000 s
- Illuminator Number : 2 (IR light); 2 (warm light)
Lens
- Focal Length : 4.0 mm
- Max. Aperture : F1.6
- Field of View : H: 80.4°; V: 58.1°; D: 104.8°
- Close Focus Distance : 0.3 m
PTZ
- Pan/Tilt Range : Pan: 0° to 345° / Tilt: 0° to +80°
- Preset : 300
Smart Event
- IVS : Tripwire; intrusion,linkage tracking
- Human Detection : Yes
- SMD : SMD3.0
Active Deterrence
- Light Warning : Warm light warning / Flash duration: 5 s–30 s / Flash frequency:high, medium, low
- Sound Warning : Offers 1 sound alarm and 10 custom sound alarms can be imported / Sound can be set from 0%–100% / Play times can be set from 1-10
Video
- Video Compression : Smart H.265+;H.265;Smart H.264+;H.264;H.264B;MJPEG(Sub Stream 1)
- Resolution : 5M (2560 × 1920); 4M (2560 × 1440); 3M (2304 × 1296); 1080p (1920 × 1080); 720p (1280 × 720); D1 (704 × 576/704 × 480); CIF (352 × 288/352 × 240)
- Video Frame Rate : Main stream: 5M/4M/3M/1080p/1.3M/720p@(1–25/30 fps)
- Video Bit Rate : H264: 88 kbps-8,192 kbps / H265: 35 kbps-8,192 kbps
- Day/Night : Auto (ICR); Color/B/W
- WDR : DWDR
- Image Rotation : 180°
Audio
- Audio Compression : PCM; G.711a; G.711Mu; G.726
Network
- Network Port : RJ-45 (10/100 Base-T)
- Wi-Fi Standard : IEEE802.11b;IEEE802.11g;IEEE802.11n
- Wi-Fi Frequency Range : 2.4 GHz
- Power Transmission : ≤20 dBm@2400–2483.5 MHz
- Browser : IE: IE 7 and later versions; Chrome; Firefox; Safari
- Management Software : Smart PSS;DMSS;Player;ConfigTool;NVR;Smart Player
- Mobile Client : iOS;Android
Storage
Micro SD card (support max. 256 GB) (64GB up to 5.6 days / 128GB up to 11.3 days / 256 GB up to 22.6 days ) (Using VBR Encoding ) / FTP
Certification
- Certifications : CE
Power
- Power Supply : 12 VDC, 1 A ± 10% (included)
Environment
- Operating Temperature : –30 °C to +55 °C
- Operating Humidity : ≤95%
Structure
- Product Dimensions : 140.5 mm × Φ111.0 mm
- Net Weight : 0.5 kg
- Gross Weight : 1 kg
| Type | Outdoor |
| Resolution | 5MP |
| Lens Type | Fixed Lens |
| Spotlight | Yes |
| AI | Human Detection,Vehicle Detection, Auto Tracking |
| Siren | Yes |
| Smart Tracking | Yes |
| Two-Way Audio | Yes |
| Capacity | Up to 256GB SD |
