Dahua Alarm Automation WallSwitch - ARM7012-W2(868) - Alarm Automation WallSwitch
Frequency-hopping, two-way communication for stable links; jamming detection and AES128 encryption; cloud updates with auto-restore; overheat/overload protection; monitors voltage, current, and energy.
Please Note
The website is currently being actively developed, you are welcome to place the order and in 99% of the cases your order will be processed as usual, but in some cases there may be a delay or the price may change. We will notify you if there are any issues.
Discontinued
This item was discontinued and currently is not available for order on our website. The item may become available soon. Please contact us if you need more information regarding the upcoming arrivals.
- Frequency hopping and two-way communication technology ensure that communication is stable
- Supports jamming detection and communication encryption
- Supports cloud update and automatically restores when cloud update fails
- Overheat and overload protection
- Monitors voltage, current and energy consumption
Port
- Relay Output : 1, NO/NC (100–240 VAC, Max 13A)
Function
- Indicator Light : 1 for multiple statuses (pairing, communication)
- Button : 1
- Remote Update : Cloud update
Technical
- Test Mode : Yes
Wireless
- Carrier Frequency : 868.0 MHz–868.6 MHz
- Communication Mechanism : Two-way
- Communication Distance : 1200 m in open areas
- Encryption Mode : AES128
- Frequency Hopping : Yes
General
- Power Supply : 100–240 VAC, 50/60 HZ
- Operating Temperature : –10 °C to +55 °C (indoor)
- Operating Humidity : 10%–90% (RH)
- Storage Temperature : –10 °C to +55 °C
- Storage Humidity : 10%–90% (RH)
- Product Dimensions : 39 mm × 33 mm × 19 mm
- Packaging Dimensions : 95 mm × 59.5 mm × 30.5 mm
- Net Weight : 45 g
- Gross Weight : 60 g
- Installation : Wall mount
- Casing Material : Plastic
- Certifications : CE
