Dahua CAT6 OFC Cable - PFM920-6U - 305m 0.57mm Black Outdoor
Outdoor Cat6 UTP cable, 305 m per carton, 0.57 mm Oxygen-Free Copper conductors, MDPE outer sheath, Black; PoE-capable.
Please Note
The website is currently being actively developed, you are welcome to place the order and in 99% of the cases your order will be processed as usual, but in some cases there may be a delay or the price may change. We will notify you if there are any issues.
Discontinued
This item was discontinued and currently is not available for order on our website. The item may become available soon. Please contact us if you need more information regarding the upcoming arrivals.
| Ethernet Cables - AWG | 23 AWG |
|---|---|
| Ethernet Cables - Length Range | Other |
| Ethernet Cables - PoE Compatible | Yes |
- 305m (1000 ft)/carton outdoor UTP CAT6, power over Ethernet, compatible with one cable
- High-purity Oxygen-Free Copper conductor material
- Customized MDPE outer sheath; meet ANSI/TIA 568-C.2 flame retardant class certified
- Environmentally friendly and all materials used are RoHS compliant
Conductor
- Material : Oxygen free copper (99.97% purity)
- Diameter : 0.57 mm ± 0.02 mm
- Wire Gauge : 23AWG
Insulation
- Material : HDPE
- Min. Average Thickness : 0.21 mm
- Diameter : 1.02 mm ± 0.06 mm
- Color : 8-core, Blue, white/blue; orange, white/orange; green, white/green; brown, white/brown
Rip Cord
- Material : Polyester
- Specification : 500D
Separator
- Material : PE
- Dimension : Translucent 4.5 × 0.4 mm
Wrap
- Material : Polyester tape (transparent)
- Dimension : W: 25mm±2mm*T: 0.026mm±0.02mm
Sheath
- Material : MDPE
- Min. Average Thickness : 0.7 mm
- Diameter : 6.2 mm ± 0.4 mm
- Color : Black
Electrical
- Max. DC Resistance of a Single Conductor : 7.35Ω/100 m
- Min. Insulation Resistance : 5000MΩ·km
- Max. DC Resistance Unbalance : 2% (pair intra), 4% (pairs inter)
- Dielectric Strength : No breakdown with 1KV DC for 1 min
Transmission
- Characteristic Impedance : 100 ± 15Ω
- Near End Cross Talk : ≥39.30 dB/100 m@250 MHz
- Max. Attenuation : 32.8 dB/100 m@250 MHz
- Return Loss : ≥17.3 dB/100 m@250 MHz
Mechanical
- Tensile Strength : Sheath≥12 MPa, insulation≥16 MPa
- Elongation at Break : Sheath≥350%, insulation≥300%
- Installation Bending Radius : >8 times of outer cable diameter
- Conductor Elongation at Break : ≥15%
Environmental
- Shrinkage of Insulation : ≤5%
- Color Migration Resistance of Insulation : No migration
- Low Temperature Bending Test : No cracking after the test
- Heat Shock Test : No cracking after the test
- Operation Temperature : –20°C to +60°C (–4°F to 140°F)
- Installation Temperature : 0°C to +50°C (32°F to 122°F)
- Storage Temperature and Humidity : –10°C to +40°C (14°F to 104°F), <60% (RH)
Packaging
- Length : 305m ± 2 m
- Packaging Dimensions : 476mm × 476 mm × 222 mm (L × W × H)
- Net Weight : 11.7kg±0.6kg
- Gross Weight : 12.7kg±0.6kg
Executive Standard
- Executive Standard : ANSI/TIA 568-C.2
| Type | Cat6 |
| Cable Type | UTP |
| Conductor | Pure Copper |
| Environment | Outdoor |
| Length | 305m |
| Colour | Black |
