Dahua Alarm Siren Intercom Indoor - ARA14-W2(868) - Indoor
Two-way RF intercom with high-decibel alarm; supports multiple alarm sounds; configurable arming/disarming prompt and LED indicator.
Please Note
The website is currently being actively developed, you are welcome to place the order and in 99% of the cases your order will be processed as usual, but in some cases there may be a delay or the price may change. We will notify you if there are any issues.
Discontinued
This item was discontinued and currently is not available for order on our website. The item may become available soon. Please contact us if you need more information regarding the upcoming arrivals.
| Sirens - Placement | Indoor |
|---|---|
| Sirens - Power | Battery |
- Two-way talk via RF transmission.
- High-decibel alarm sound.
- Multiple alarm sounds: Fire, medical, intrusion, panic, and more.
- Configurable arming/disarming prompt sound and LED indicator.
- Supports panic button.
- Offers voice talk through the app and SIP.
- Suitable for the ARC3800H series only, excluding the ARC3000H and ARA43 series.
Port
- Microphone : Yes
Video & Audio
- Two-way Audio : Yes
Function
- Button : 1 × panic button, 1 × power button
- Buzzer : Yes
- Remote Update : Cloud update
- Low Battery Detection : Yes
- Tamper : Yes
Technical
- LED Indicator : Red, blue and green indicators
- Scenario : Indoor
- Operating Current : 1.5 A (Max), 20 uA (Standby) (Battery 3V); / 0.4 A (Max), 1.5mA (Standby) (DC 12V)
- Sound and Light Alarm : Yes
- Sound Pressure : Volume high 100db (A )1 m / Volume minimum 77.6 db (A)1 m
Wireless
- Carrier Frequency : 865.34 MHz–868.60 MHz
- Transmitter Power (EIRP) : Limit 25 mW
- Communication Mechanism : Two-way
- Communication Distance : 1600m（alarm transmission），1000m（intercom）
- Encryption Mode : AES128
- Frequency Hopping : Yes
General
- Power Supply : 4 × CR123A battery/9-15 VDC
- Battery Model : CR123A
- Standby Time : 3 years (when triggered once every 2 weeks and alarms for 120 sec).
- Power Consumption : 4.5 W (Max), 0.4 mW (Standby)
- Operating Temperature : -10 °C to +55 °C (+14 °F to +131 °F) (indoor)
- Operating Humidity : 10%–90% (RH)
- Product Dimensions : 133.0 mm × 133.0 mm × 35.5 mm (5.24" × 5.24" × 1.40"）
- Net Weight : 377 g (0.83 lb)
- Gross Weight : 507 g (1.12 lb)
- Installation : Wall mount
- Casing Material : PC + ABS
- Appearance Color : White
- Certifications : CE / EN 50131-1:2006+A1:2009+A2:2017+A3:2020 / EN 50131-4:2019 / EN 50131-6:2017+A1:2021 / EN 50131-5-3:2017 / Security Grade 2 / Environmental Class II
- Anti-corrosion Level : Basic Protection
- Storage Temperature : –10 °C to +55 °C (+14 °F to +131 °F)
- Storage Humidity : 10%–90% (RH)
- Packaging Dimensions : 170 mm × 166 mm × 55 mm (6.69" × 6.54" × 2.71"）
| Connectivity | Wireless |
| Installation | Wall |
| Battery | Up to 3 Years |
| Communication | 2Way |
| Range | Up to 1600 meters |
| Certification | Grade 2,CE |
| Sound | Up to 100 dB |
