Dahua Alarm Wireless PIR Camera Detector - ARD1731-W2(868) - Alarm Wireless PIR Camera Detector
Wireless Dahua alarm PIR camera detector with up to 1600x1200 resolution, RF-HD transmission, 6 HD images in up to 10 seconds, and one-week cloud cache for videos and images.
Please Note
The website is currently being actively developed, you are welcome to place the order and in 99% of the cases your order will be processed as usual, but in some cases there may be a delay or the price may change. We will notify you if there are any issues.
Discontinued
This item was discontinued and currently is not available for order on our website. The item may become available soon. Please contact us if you need more information regarding the upcoming arrivals.
| Security Sensors - Type | PIR Motion |
|---|---|
| Security Sensors - Connectivity | Wireless (433/868 MHz) |
| Security Sensors - Power | Battery |
- Maximum resolution 1600*1200
- Based on the RF-HD image transmission technology, transmission of 6 HD images with resolution of 1600*1200 needs up to 10 seconds
- One-week cloud cache for videos and images
- Temperature monitoring
- Offers frequency hopping and two-way communication technology,ensuring the stability of communication
- Cloud update and automatic recovery from update failure
Video
- Field of View : 88° (H);68° (V)
- Image Type : JPEG
- Resolution : 1600 × 1200; 1280 × 960; 640 × 480; 320 × 240
- Frame Rate : 2
- Illumination Mode : Infrared Light
- Illumination Range : 12 m (39.37 ft)
- Day/Night Switch : Color/Black & White
Function
- Indicator Light : 1 × green alarm indicator
- Button : 1 × power switch
- Remote Update : Cloud update
- Low Battery Detection : Yes
- Battery Level Display : Yes
- Tamper : Tamper alarm
- Signal Strength : RF Signal test / RF-HD signal test
Technical
- Detection Mode : PIR
- Sensitivity : 3 levels adjustable
- Detection Range : 12 m (86°) with installation height of 2.2 m
- Detection Speed : 0.3 m/s–3 m/s
- Pet Immunity Level : ≤18 kg
- White Light Resistance Level : 2000 lux
- Two-way Digital Temperature Compensation : Yes
- Scenario : Indoor
- Operating Current : 65 μA
- Alarm Current : Day: 170 mA (Avg); 800 mA (Max) / Night: 230 mA (Avg); 2.8 A (Max)
Wireless
- Carrier Frequency : RF:868.0 MHz–868.6 MHz
- RF-HD:2.4GHz
- Communication Distance : RF:Up to 1,600 m in an open space / RF-HD:Up to 300 m in an open space
- Communication Mechanism : Two-way
- Frequency Hopping : Yes
- Encryption Mode : AES128
General
- Power Supply : CR123A*3
- Battery Life : 4 years (if triggered twice a week with a battery efficiency of 70%)
- Operating Temperature : –10 °C to +55 °C (+14 °F to +131 °F) (indoor)
- Operating Humidity : 10%–90% (RH)
- Product Dimensions : 127.6 mm × 71.0 mm × 53.2 mm
- Packaging Dimensions : 121.0 mm × 65.0 mm × 170.0 mm
- Net Weight : 202 g
- Gross Weight : 333 g
- Installation : Wall mount
- Casing : PC + ABS
- Certifications : CE
| Connectivity | Wireless |
| Installation | Wall |
| Battery | Up to 4 Years |
| Communication | 2Way |
| Certification | CE |
| Pet Immune | Up to 18 Kg |
