Dahua Crimping Tool for RJ45 Plugs - PFM915 - Crimping Tool for RJ45 Plugs
Multi-functional RJ45 Ethernet crimping tool supporting 4P, 6P, and 8P.
Please Note
The website is currently being actively developed, you are welcome to place the order and in 99% of the cases your order will be processed as usual, but in some cases there may be a delay or the price may change. We will notify you if there are any issues.
Discontinued
This item was discontinued and currently is not available for order on our website. The item may become available soon. Please contact us if you need more information regarding the upcoming arrivals.
| Crimp & Test Tools - Tool Type | Crimper |
|---|---|
| Crimp & Test Tools - Connector Support | RJ45 |
4P 6P 8P Ethernet Crimper
- Designed to be multi-functional, it can cut, trim and strip wires.
- Engineered with an A3 carbon steel crimper body, it is sturdy, durable and resistant to impacts.
- Built with the SK5 blade, it cuts fast without leaving behind burrs.
- The crimper naturally rebounds with its built-in spring when clamping and does not get stuck when released.
- Supports crimping network cables and RJ-45 connectors.
Function
- Application Range : RJ-45, RJ-11
- Wire Cutting : Yes
- Wire Trimming : Yes
- Wire Stripping : Yes
Material
- Crimper Body : A3 steel
- Crimper Head : PC
- Handle : PP and TPR
- Blade : SK5
- Hardness : Gear hardness: HRA40–50 degrees, Blade hardness: HRC55–67 degrees
Structure
- Appearance Color : Blue handle and black pliers body
- Product Dimensions : 195 mm × 118 mm × 18 mm (7.68" × 4.65" × 0.71")
- Packaging Dimensions : 270 mm × 120 mm × 20 mm (10.63" × 4.72" × 0.79")
- Net Weight : 0.34 kg (0.76 lb)
- Gross Weight : 0.40 kg (0.87 lb)
Environment
- Operating Temperature : 0 °C to +50 °C (+32 °F to +122 °F)
- Operating Humidity : 20%–70%
