Citronic Power Amp - PLX2800 - 2x1400W 2ohm 172.216UK
19" rackmount 2U dual-channel power amplifier with dual-fan cooling, Class H, balanced 6.3mm/XLR inputs, and 2 speaker outputs.
Please Note
The website is currently being actively developed, you are welcome to place the order and in 99% of the cases your order will be processed as usual, but in some cases there may be a delay or the price may change. We will notify you if there are any issues.
Discontinued
This item was discontinued and currently is not available for order on our website. The item may become available soon. Please contact us if you need more information regarding the upcoming arrivals.
19" rackmount 2U power amplifier with dual fan cooling and class H architecture for safe, reliable power delivery. Balanced inputs via 6.3mm jack or XLR sockets, speaker outputs on 2 SPK connectors or 4mm binding posts. High power output stable down to 2 Ohms load per side can also be bridged mono to 4 Ohms. Switchable ground lift, bridge mode and clip limiter
- Bridge mode for high power mono operation
- Output stable down to 2 Ohms
- Removable handles for low profile install
- Switchable clip limiter
- Power supply : 240Vac, 50Hz (IEC)
- Controls: Level channel 1, level channel 2, ground, mode, clip limiter
- Input impedance: 20k ohms
- Frequency response: 5Hz - 50kHz
- Total harmonic distortion: 0.05%
- Slew rate : 40V/us
- Damping factor: >400
- Protection: Short-circuit, overload, D.C. and thermal protect
- Dimensions: 482 x 453 x 88mm
- Output power :2 x 1400Wrms @2 ohms
- Power RMS @ 2 Ohms:2 x 1400W
- Power RMS @ 4 Ohms: 2 x 1050W
- Power RMS @ 8 Ohms: 2 x 600W
- Power RMS bridge @ 4 Ohms: 2300W
- Power RMS bridge @ 8 ohms: 1750W
- Weight: 25.0kg
| Channels | Dual |
| Power (8ohm) | 2 x 600 |
| Power (4ohm) | 2 x 1050 |
| Power (2ohm) | 2 x 1400 |
| Amplifier Class | Class H |
| 2ohm Stable | Yes |
| Bridge Mode | Yes |
| Warranty | 3 Years |
