Adastra Amplifier - RMS605 - 100V 5x60W Class D Amplifier
RMS-series 100V multi-zone amplifier with 5 zones and independent line inputs; supports 100V or 4-16 Ohm speakers.
Please Note
The website is currently being actively developed, you are welcome to place the order and in 99% of the cases your order will be processed as usual, but in some cases there may be a delay or the price may change. We will notify you if there are any issues.
Discontinued
This item was discontinued and currently is not available for order on our website. The item may become available soon. Please contact us if you need more information regarding the upcoming arrivals.
RMS-series Multi Zone 100V Amplifiers
Multi-channel 100V slave amplifier with independent outputs for 100V or 4-16 Ohm speakers. Each amplifier channel has its own independent line input, which can be switched to a global auxiliary, providing the option of the same input to several of the amplifier channels if required. A paging microphone input is provided for voice alerts and a 24V mute terminal can be connected to an alarm panel for emergency evacuation override. Class D circuit design and efficient toroidal transformers have enabled a design which fits into a 1U rack-mount housing. The RMS-series amplifiers can be applied as high power slave units or equally as a fully independent zoning system for a multi-room installation.
- Independent high efficiency class-D amplifiers
- Outputs for 100V or 4-16 Ohm speakers
- Separate channel inputs and optional global aux input
- Paging microphone input with vox override
- Switchable +20V phantom power for paging microphone
- 24V contacts for emergency muting
- Fuse T2AL
- Channel inputs 5 x L+R RCA or balanced terminal
- Power rms : 100V line 5 x 60W
- Power rms : 4 Ohms 5 x 60W
- Output connection 5 x 100V or 4 Ohm (Euroblock terminal)
- Auxiliary output N/A
- Dimensions 482 x 330 x 42mm
- Weight 8.17kg
| Amplifier Type | Slave Amp |
| Power | 300W |
| Zones | 5 |
| Zone Control | Volume |
| Rack Mountable | Yes |
