FTE Multiband Amplifier - ZM350 - LTE 3U 2V Aluminium
LTE multiband amplifier with 5 inputs (2 VHF, 3 UHF), 1 output, 34 dB per output, total 114 dB, aluminium enclosure.
Please Note
The website is currently being actively developed, you are welcome to place the order and in 99% of the cases your order will be processed as usual, but in some cases there may be a delay or the price may change. We will notify you if there are any issues.
Discontinued
This item was discontinued and currently is not available for order on our website. The item may become available soon. Please contact us if you need more information regarding the upcoming arrivals.
- Inputs and bands 5: 2 VHF * / 3 UHF (C21-C60)
- Frequencies 47 - 230 / 470 - 790
- Gain: VHF 1: 29 / VHF 2: 18 , UHF: 34
- Regulation VHF: 20, UHF: 20
- Output level DIN 45004 B IMA3 -60 dB:114 dBµV
- DC pass: Yes / 1 UHF configurable through jumper 0 / 12 VDC (Max. 200 mA)
- Feeding: 230 VAC / 50 Hz / 7,2 W
- Protection index: IP 40 Aluminium box
* Only 1 VHF with jumper is incorporated. For a second VHF input, complementary filters are required.
| Type | Multiband Amplifier |
| Inputs | 5 |
| UHF Inputs | 3 |
| VHF Inputs | 2 |
| Outputs | 1 |
| Gain per output | 34db |
| Total Output | 114db |
| Other | Aluminium |
