Reolink WIFI Outdoor PTZ Camera 4K 3x Optical Zoom E1 Outdoor Pro - E560 - WIFI Outdoor PTZ Camera 4K 3x Optical Zoom
4K 8MP smart PTZ Wi‑Fi 6 camera with auto tracking, dual-band 2.4/5 GHz, 3x optical zoom, 355° pan, 50° tilt, color night vision.
Please Note
The website is currently being actively developed, you are welcome to place the order and in 99% of the cases your order will be processed as usual, but in some cases there may be a delay or the price may change. We will notify you if there are any issues.
Discontinued
This item was discontinued and currently is not available for order on our website. The item may become available soon. Please contact us if you need more information regarding the upcoming arrivals.
| IP Cameras - Form Factor | PTZ |
|---|---|
| IP Cameras - Resolution | 8 MP (4K) |
| IP Cameras - Audio | Mic + Speaker (2-way) |
| IP Cameras - Storage | microSD |
- 4K 8MP Smart PTZ Wi-Fi 6 Camera with Auto Tracking
- 2.4/5 GHz Dual-Band Wi-Fi
- 3X Optical Zoom
- 355° Pan & 50° Tilt
- Color Night Vision
Video & Audio
- Image Sensor : 1/2.8" CMOS Sensor
- Video Resolution : Default: 3840 x 2160 (8.0 megapixels) at 20 frames/sec
- Lens : f=2.8 - 8mm F=1.6, with IR cut
- Zoom : 3X optical zoom
- Video Format : H.265
- Field of View : Horizontal: 94°- 50° / Vertical: 53°- 30°
- Pan/Tilt Angle : Horizontal: 355° / Vertical: 50°
- Day & Night : IR-cut filter with auto-switching
- Infrared Night Vision : Up to 12 meters (LED: 12pcs/1.6W/850nm)
- Color Night Vision : Spotlights: 4pcs/2.7W/6500K/180Lumens
- Audio : Two-Way Audio
Interface
- Power : DC power port : DC 12.0V⎓1A, <12W
- System : Reset button
- Ethernet : One 10M/100Mbps RJ45
- Storage : Micro SD card slot (Max. 256GB)
- Audio : Built-in microphone and speaker
Software Features
- Frame Rate : Mainstream: 2fps - 25fps (default: 20fps) / Substream: 4fps - 15fps (default: 10fps)
- Code Rate : Mainstream: 1024Kbps - 8192Kbps (default: 4096Kbps) / Substream: 64Kbps - 512Kbps (default: 256Kbps)
- Browsers Supported : Edge, Chrome, Firefox, Safari
- OS Supported : PC: Windows, Mac OS; Smartphone: iOS, Android
- Smart Alarm : Motion detection/person detection/vehicle detection
- Record Mode : Motion recording (default); scheduled recording; 24/7 recording
- Protocols & Standards : HTTP, HTTPS, SSL, TCP/IP, UDP, UPnP, RTSP, RTMP, SMTP, NTP, DHCP, DNS, DDNS, P2P, FTP
- Maximal User Access : 20 users (1 admin account & 19 user accounts); supports up to 12 simultaneous video streams (10 substreams & 2 mainstreams)
- Work with : Google Assistant/Reolink Cloud (available in some countries)
Wireless Standard
- Wi-Fi : IEEE 802.11a/ac/ax/ b/g/n
- Operating Frequency : 2.4GHz/5GHz
- Wireless Security : WPA/WPA2/WPA3
Working Environment
- Temperature : -10°C~+55°C
- Humidity :Operating humidity: 20% ~ 85%
- Waterproof :IP64
Size & Weight
- Dimension : Φ85×118mm
- Weight : 415g
| Type | Outdoor |
| Battery Powered | No |
| Resolution | 4K |
| Lens Type | PTZ |
| Spotlight | Yes |
| Smart Tracking | Yes |
| Two-Way Audio | Yes |
| Capacity | Up to 256GB SD |
