Lenkeng KVM HDMI Extender over Ethernet 4K60Hz 70m Loop IR - LKV565KVM -
HDMI KVM extender kit with zero-latency transmission; extends 4K60Hz HDMI up to 70m over CAT6/6A/7.
Please Note
The website is currently being actively developed, you are welcome to place the order and in 99% of the cases your order will be processed as usual, but in some cases there may be a delay or the price may change. We will notify you if there are any issues.
Discontinued
This item was discontinued and currently is not available for order on our website. The item may become available soon. Please contact us if you need more information regarding the upcoming arrivals.
| Docks & Hubs - Video Outputs | HDMI |
|---|---|
| Docks & Hubs - Max Resolution | 4K60 (single) |
| Docks & Hubs - Ethernet | 1GbE |
This is an HDMI point-to-point extender kit, it can realize zero-latency transmission. The 4K@60Hz HDMI signal can be extended by 70m through CAT6/6A/7 network cable. It supports HDMI loop out, KVM function, 3.5mm stereo audio output, etc. This kit is a reliable, ultrahigh- definition video transmission solution, which is widely used in security monitoring, home theater, broadcasting, training and other fields.
- ipcolor IMAGE
- 4K@60Hz
- HDR
- Visually Lossless
- Ultra Low Latency
- KVM
- Widescreen Resolutions
- 70M
- HDMI Loop-out
- Auto Down-Scaling
- 3.5mm L/R Output
- Lightning Protection-Surge Protection-ESD Protection
- HDMI length ≤ 5m
- Maximum transfer rate 18Gbps
- Compatibility HDMI 2.0
- HDCP 2.2
- Resolutions 480i@60Hz, 480p@60Hz, 576i@50Hz, 576p@50Hz, 720p@50/60Hz, 1080i@50/60Hz, 1080p@50/60Hz, 3840x2160@24/25/30/50/60Hz, 4096x2160@24/25Hz, 3440x1440, 2560x1440, 2560x1080, 2048x1080, 1920x1440, 1920x1200, 1280x960, 1280x800, 1280x768, 1680x1050, 1360x768, 1366x768, 1600x900, 1024x768, 800x600
- Transmission distance CAT6/6A/7 ≤ 60m
- Audio formats LPCM/DTS-Audio/Dolby Digital 5.1CH/Dolby Atmos
- USB version USB 1.1, compatible with USB 1.0
- Power Supply TX: DC 5V/2A，RX: PoC (Powered by TX)
- Power Consumption TX+RX<8W
- Working -10℃~60℃
- Storage temperature -30℃~70℃
- Humidity 0~90% RH (no condensation)
- Housing lron
- Weight TX: 146g，RX: 146g
- Color Black
- Dimensions 85.0(L)x75.5(W)x21.5(H)mm
- Protection ESD protection
- 1a Contact discharge level 2 (±4KV)
- 1b Air discharge level 3 (±8KV)
- Implementation of the standard: IEC61000-4-2
- Lightning protection, Surge protection
| Connectivity | HDMI |
| Type | KVM |
| Transmission | Single CAT6 |
| Resolution | 4K60Hz |
| Distance | 70m |
| Loop through | Yes |
