Lian Li SX1000P Platinum 1000W ATX 3.1 Fully Modular PSU (White/Boxed)
Lian Li SX 1000W Platinum PSU with 80 PLUS Platinum efficiency, ATX 3.1 compliance, fully modular design, fanless operation up to 40% load, and 10-year warranty. Features Japanese capacitors and compact 140mm form factor.
Please Note
The website is currently being actively developed, you are welcome to place the order and in 99% of the cases your order will be processed as usual, but in some cases there may be a delay or the price may change. We will notify you if there are any issues.
Discontinued
This item was discontinued and currently is not available for order on our website. The item may become available soon. Please contact us if you need more information regarding the upcoming arrivals.
| PSU (Power Supplies) - Wattage | 1000 - 1199 W |
|---|---|
| PSU (Power Supplies) - Efficiency Rating | 80 Plus Platinum |
| PSU (Power Supplies) - Color | White |
| PSU (Power Supplies) - Modularity | Fully modular |
| PSU (Power Supplies) - PCIe GPU Connectors | 2x 12V-2x6 5x 8/6 pins |
| PSU (Power Supplies) - Length | Up to 140 mm |
| PSU (Power Supplies) - EPS CPU Connectors | 1x 4+4pin EPS/ATX12V |
Experience premium power delivery with the Lian Li SX Platinum 1000W, a fully modular ATX 3.1 compliant power supply engineered for high-performance builds. Certified with 80 PLUS Platinum efficiency, this unit delivers up to 92% efficiency at 50% load, ensuring cooler operation, quieter acoustics, and lower energy costs. The intelligent fanless cooling system operates silently at loads up to 40%, automatically engaging the 120mm FDB fan only when needed for optimal thermal management.
Built with premium Japanese capacitors (Rubycon, Nippon Chemi-Con, or Nichicon 105C-rated), the SX Platinum provides exceptional voltage regulation, minimal ripple, and long-term reliability even under demanding conditions. The compact 140mm form factor fits seamlessly into most PC cases while leaving ample internal space. Fully modular cabling with individually sleeved braided cables and cable combs ensures clean cable management and professional aesthetics. Native support for ATX 3.1 and PCIe 5.1 standards includes dual 12V-2x6 connectors for next-generation GPUs, complemented by six 6+2 pin PCIe connectors for maximum compatibility.
Comprehensive protection circuitry (OCP, OVP, OTP, OPP, SCP, UVP, NLP, SIP) safeguards your system against overcurrent, overvoltage, overtemperature, and short-circuit conditions. Backed by a 10-year limited warranty, this power supply combines cutting-edge efficiency with proven reliability for discerning enthusiasts and professionals.
- Wattage: 1000W continuous output
- Efficiency: 80 PLUS Platinum (92% at 50% load)
- Form Factor: ATX 3.1 compliant, 140mm compact length
- Modularity: Fully modular with braided cables and combs
- GPU Power: 2x 12V-2x6 connectors + 6x 6+2 pin PCIe connectors
- CPU Power: 1x 12+4pin EPS/ATX12V connector
- Cooling: 120mm FDB fan with fanless mode up to 40% load
- Capacitors: 100% Japanese 105C-rated (Rubycon/Nippon Chemi-Con/Nichicon)
- Protection: OCP, OVP, OTP, OPP, SCP, UVP, NLP, SIP
- Warranty: 10 years limited
| Model | SX1000P.W |
| Wattage | 1000W |
| Efficiency Certification | 80 PLUS Platinum |
| Maximum Efficiency | 92% at 50% load |
| ATX Version | ATX 3.1 |
| PCIe Standard | PCIe 5.1 compliant |
| Form Factor | ATX |
| Modularity | Fully modular |
| Dimensions (Unit) | 150mm(W) x 86mm(H) x 140mm(D) |
| Weight (Unit) | 2.4 kg (84.64 oz) |
| Color | White |
| Max DC Output | 1000W |
| Combined +3.3V & +5V Output | 100W |
| Combined +12V Output | 999.6W |
| Input Voltage | 100-240Vac |
| Input Current Range | 6-12A, 50-60Hz |
| Power Factor Correction | Active PFC, PF > 0.95 at full load @ 115Vac, 60Hz |
| Fan Type | 120mm FDB (Fluid Dynamic Bearing) |
| Max Fan Speed | 2000 RPM |
| Fanless Operation | Up to 40% load |
| Average Fanless Operating Time | Minimum 100,000 hours @ 25°C / 75% load |
| GPU Power Connectors | 2x 12V-2x6 (ATX 3.1 native) + 6x 6+2 pin PCIe (3x 8-pin + 2x 6+2 pin graphics) |
| CPU Power Connectors | 1x 12+4pin EPS/ATX12V |
| SATA Connectors | 8x SATA |
| Molex Connectors | 4x Molex |
| Capacitors | 100% Japanese 105°C rated (Rubycon, Nippon Chemi-Con, or Nichicon) |
| Protection Features | OCP, OVP, OTP, OPP, SCP, UVP, NLP, SIP |
| Cabling | Fully modular with individually sleeved braided cables and cable combs included |
| Warranty | 10 years limited (parts and labor) |
| Compliance | ATX 3.1, PCIe 5.1, Intel standards |
