Intel S1151 Xeon Tray - E-2234 - 4x3.6 71W
Intel Xeon E-2234 processor for server/workstation, LGA 1151 socket, tray packaging, 3.6 GHz base, 4 cores, 8 threads, 71 W TDP, 14 nm.
Please Note
The website is currently being actively developed, you are welcome to place the order and in 99% of the cases your order will be processed as usual, but in some cases there may be a delay or the price may change. We will notify you if there are any issues.
Discontinued
This item was discontinued and currently is not available for order on our website. The item may become available soon. Please contact us if you need more information regarding the upcoming arrivals.
| CPU (Processors) - Unlocked/Overclockable | No |
|---|---|
| CPU (Processors) - Cooler Included | No |
Intel Xeon E-2234. Prozessorfamilie: Intel Xeon E. Prozessorsockel: LGA 1151 (Socket H4). Prozessor Lithografie: 14 nm. Speicherkanäle: Zweikanalig. Maximaler interner Speicher. vom Prozessor unterstützt: 128 GB. Speichertypen. vom Prozessor unterstützt: DDR4-SDRAM. Marktsegment: Server. PCI Express Konfigurationen: 1x16. 2x8. 1x8+2x4. Unterstützte Befehlssätze: SSE4.1. SSE4.2. AVX 2.0. Intel® Turbo Boost Technology 2.0 frequency: 4.8 GHz. Prozessor-Paketgröße: 37.5mm x 37.5mm
| Prozessorhersteller | Intel |
| Prozessor | E-2234 |
| Grundfrequenz des Prozessors | 3.6 GHz |
| Prozessorfamilie | Intel Xeon E |
| Anzahl Prozessorkerne | 4 |
| Prozessorsockel | LGA 1151 (Socket H4) |
| Komponente für | Server/Arbeitsstation |
| Prozessor Lithografie | 14 nm |
| Prozessor-Threads | 8 |
| Systembus-Rate | 8 GT/s |
| Prozessorbetriebsmodi | 64-Bit |
| Prozessor Boost-Frequenz | 4.8 GHz |
| Prozessor-Cache | 8 MB |
| Prozessor Cache Typ | Smart Cache |
| Thermal Design Power (TDP) | 71 W |
| Verpackungsart | Einschub |
| Prozessor Codename | Coffee Lake |
| ARK Prozessorerkennung | 191039 |
| Maximaler interner Speicher. vom Prozessor unterstützt | 128 GB |
| Speichertypen. vom Prozessor unterstützt | DDR4-SDRAM |
| Speichertaktraten. vom Prozessor unterstützt | 2666 MHz |
| Speicherkanäle | Zweikanalig |
| Feature | Intel® vPro™ Platform Eligibility |
| Eingebautes Grafikkartenmodell | Nicht verfügbar |
| Separates Grafikkartenmodell | Nicht verfügbar |
| Marktsegment | Server |
| Maximale Anzahl der PCI-Express-Lanes | 16 |
| PCI-Express-Slots-Version | 3.0 |
| PCI Express Konfigurationen | 1x16. 2x8. 1x8+2x4 |
| Unterstützte Befehlssätze | SSE4.1. SSE4.2. AVX 2.0 |
| Skalierbarkeit | 1S |
| CPU Konfiguration (max) | 1 |
| PCI Express CEM Revision | 3.0 |
| Exportkontroll-Klassifizierungsnummer (ECCN) | 5A992C |
| Warenklassifizierungssystem zur automatisierten Nachverfolgung (CCATS) | G077159 |
| Intel® Turbo-Boost-Technologie | 2.0 |
| Intel® Turbo Boost Technology 2.0 frequency | 4.8 GHz |
| Tcase | 69.3 °C |
| Tjunction | 100 °C |
| Startdatum | Q2'19 |
| Maximale Auflösung & Bildwiederholrate (DisplayPort) | N/A |
| Produkttyp | Processor |
| Status | Launched |
| Maximaler Speicher | 128 GB |
| Unterstützte Arbeitsspeicher | DDR4-SDRAM |
| Busgeschwindigkeit | 8 GT/s |
| Prozessor-ID | N/A |
| Instandhaltungsstatus | Baseline Servicing |
| Warentarifnummer (HS) | 85423119 |
| Prozessor-Paketgröße | 37.5mm x 37.5mm |
| RAM-Speicher maximal | 128 GB |
| Grafischer Ausgang | N/A |
