4K HDMI EDID Emulator - Adapter
Digitus 4K HDMI EDID Emulator Adapter reads and clones EDID data and continuously emulates an HDMI monitor; supports UHD 4K2K / 60Hz and HDCP pass-through.
Please Note
The website is currently being actively developed, you are welcome to place the order and in 99% of the cases your order will be processed as usual, but in some cases there may be a delay or the price may change. We will notify you if there are any issues.
Discontinued
This item was discontinued and currently is not available for order on our website. The item may become available soon. Please contact us if you need more information regarding the upcoming arrivals.
The Digitus 4K HDMI EDID Emulator DA-70466 enables the reading and cloning of the EDID data of a connected TV/monitor/screen, and continuously emulates a connected HDMI monitor so that the signal source does not change or switch off its signal even if the connection is interrupted. It has preset EDID data (resolutions/timings) as described in the instructions. If EDID data for an individual monitor/display is missing, it can be read and cloned quickly and easily using the practical clone function. The emulator supports resolutions up to UHD 4K2K/60Hz. The DA-70466 emulator offers the ideal solution for applications with HDMI extenders, splitters, switches or converters.
| Typ | Adapter |
| Color | schwarz |
| EAN | 4016032442554 |
| Manufacturer no. | DA-70466 |
| Application example | Allows reading and cloning of EDID data |
| Area | Audio / Video |
| Connection - from | 1x HDMI (male) |
| taps | 2 |
| Characteristics | Adapter, extern |
| More information | Supports resolutions up to UHD 4K2K / 60Hz, HDCP pass-through, supports HDCP 2.2 / 1.4, supports VESA and CEA specifications |
| Notice | LED activity indicator, no external power required |
| Accessories - available | Instruction manual |
| Dimensions | Width: 20mm x Height: 13mm x Depth/Length: 44mm |
| Weight | 15 Gramm |
