Active Optical USB-C 4K Video + Data + PD Cable
10 m Active Optical USB-C cable from DeLock enabling USB-C connections to a PC, supporting USB Power Delivery (PD) 60 W and 4K video/data.
Please Note
The website is currently being actively developed, you are welcome to place the order and in 99% of the cases your order will be processed as usual, but in some cases there may be a delay or the price may change. We will notify you if there are any issues.
Discontinued
This item was discontinued and currently is not available for order on our website. The item may become available soon. Please contact us if you need more information regarding the upcoming arrivals.
The 10 meter long active USB cable 84150 from DeLock enables the connection between devices with a USB-C port and a PC or notebook with a free USB-C port. The active optical cable uses fiber optic cables to transmit high-speed signals. Compared to the traditional copper cable, the fiber optic/copper hybrid cable is softer, thinner, lighter and can transmit signals over longer distances without loss. The cable supports DisplayPort 1.4 with 2 lanes and is suitable for connecting a USB-C monitor with a resolution of up to 4K Ultra HD (3,840 x 2,160 @ 144Hz) to a computer with a USB-C interface and DisplayPort Alternate Mode support. The active optical cable enables data transfer rates up to 10 Gbps when connecting USB 10 Gbps compatible devices. Of course, USB 2.0 devices can also be connected. By supporting the USB Power Delivery standard, connected devices can be supplied with power, up to 60 watts (20V / 3A) are possible.
| Typ | Cable |
| Color | schwarz |
| EAN | 4043619841509 |
| Manufacturer no. | 84150 |
| Manufactured in | China |
| Charging function | USB Power Delivery (PD) 60 Watt |
| Application example | Connects USB-C monitors to a PC |
| Area | Data transfer |
| Connection - from | 1x USB-C (Stecker) |
| Protocol | USB4 Gen 2x1 (10 Gbit/s) |
| Video classification | DisplayPort 1.4 |
| taps | 2 |
| Characteristics | external, USB C connector can be used on both sides |
| Feature | Transmission of audio and video signals, gold-plated contacts, backwards compatible with USB 2.0 |
| More information | Fiber optic / copper hybrid cable, supports 2 lanes with DisplayPort 1.4, Display Stream Compression 1.2 (DSC) and DP Alt Mode, max. resolution (depending on the system and the connected hardware): DisplayPort 1.4 with DSC up to 3,840 x 2,160 @ 144Hz, DisplayPort 1.4 without DSC up to 3,840 x 2,160 @ 60Hz, DisplayPort 1.2 without DSC up to 3,840 x 2,160 @ 30Hz, supports HDR (High Dynamic Range), HDCP 1.4 and 2.2, Cable diameter approx. 6.5mm |
| Notice | Only compatible with DisplayPort (DP Alt-Mode) devices, not with Thunderbolt devices. Fixed signal direction for video (source/display), unspecified signal direction for data. |
| Cable length | 10 Meter |
