ICY BOX IB-HUB1419-i3 Front-Panel USB Hub Adapter – USB 3.2 Gen 1, SD/microSD (Retail)
Front-panel USB hub adapter with USB Type-E motherboard connection. Features 2× USB-A, 1× USB-C (20 Gbit/s), SD/microSD card reader, and SATA power connector.
Please Note
The website is currently being actively developed, you are welcome to place the order and in 99% of the cases your order will be processed as usual, but in some cases there may be a delay or the price may change. We will notify you if there are any issues.
Discontinued
This item was discontinued and currently is not available for order on our website. The item may become available soon. Please contact us if you need more information regarding the upcoming arrivals.
| Expansion Cards - Product Type | IO Port Expansion |
|---|---|
| Expansion Cards - Host Interface | USB (External) |
| Expansion Cards - Internal Connectivity | External Only |
| Expansion Cards - Form Factor | External Desktop |
| Expansion Cards - External Connectivity | USB Type-A USB Type-C and Thunderbolt |
The ICY BOX IB-HUB1419-i3 is a front-panel adapter that brings essential connectivity directly to your PC's front bezel. By connecting via an internal USB Type-E header on your motherboard, this adapter eliminates the need to reach around to the back of your system for frequently used ports. The compact design fits standard 5.25-inch drive bays or can be mounted in other accessible locations within your case.
This hub provides multiple connectivity options: two USB Type-A ports (5 Gbit/s each), one USB Type-C port with 20 Gbit/s throughput (USB 3.2 Gen 1), and dual card readers supporting SD and microSD cards at speeds up to 104 MB/s. The included 15-pin SATA power cable ensures stable operation, while the USB Type-E motherboard connector supports current and future hardware standards. The adapter measures 100mm × 25mm × 140mm and weighs 218 grams, making it a space-efficient solution for expanding front-panel accessibility.
Key features and specifications:
- Internal connection: USB Type-E to motherboard header
- External ports: 2× USB Type-A (5 Gbit/s), 1× USB Type-C (20 Gbit/s)
- Card readers: 1× SD 3.0 (UHS-I), 1× microSD 3.0 (UHS-I), up to 104 MB/s
- Power: 15-pin SATA to SATA power cable (20 cm included)
- Dimensions: 100mm W × 25mm H × 140mm D
- Weight: 218 grams
- Manufactured in China
| Type | Front-Panel USB Hub Adapter |
| Model | IB-HUB1419-i3 |
| Manufacturer Number | 61169 |
| Color | Black |
| Motherboard Connection | USB Type-E header |
| External USB Ports | 2× USB Type-A (5 Gbit/s), 1× USB Type-C (20 Gbit/s USB 3.2 Gen 1) |
| Maximum Transfer Rate | 20 Gbit/s (USB 3.2 Gen 1 Type-C) |
| Card Reader Type | SD 3.0 (UHS-I) and microSD 3.0 (UHS-I) |
| Card Reader Speed | Up to 104 MB/s |
| Power Connection | 15-pin SATA to SATA power cable (20 cm included) |
| Width | 100 mm |
| Height | 25 mm |
| Depth | 140 mm |
| Weight | 218 grams |
| Country of Origin | China |
| Included Accessories | USB-A to USB 20-pin cable (50 cm), 15-pin SATA to SATA power cable (20 cm), screw set |
| Multi-LUN Support | Yes (for memory cards) |
