Ubiquiti USW-Pro-XG-48-PoE: 48-port Layer 3 Etherlighting™ PoE+++ switch with 32x 10GbE ports, 16x 2.5GbE PoE ports, and 4x 25G SFP28.
Please Note
The website is currently being actively developed, you are welcome to place the order and in 99% of the cases your order will be processed as usual, but in some cases there may be a delay or the price may change. We will notify you if there are any issues.
Discontinued
This item was discontinued and currently is not available for order on our website. The item may become available soon. Please contact us if you need more information regarding the upcoming arrivals.
The Ubiquiti USW-Pro-XG-48-PoE is a professional 48-port Layer 3 Etherlighting™ PoE+++ switch. It offers 32 fast 10GbE ports, 16 flexible 2.5GbE PoE ports and 4 powerful 25G SFP28 ports for demanding networks and highest performance. Ideal for professional environments.
| Typ | Switch |
| Color | silber |
| EAN | 0810177160748 |
| Manufacturer no. | USW-Pro-XG-48-PoE |
| Design | Rack |
| Connections - Network | RJ-45 48x (of which: 16x 100/1000/2500, 32x 1000/2500/5000/10000) |
| Routing & Switching - Layer | Layer 3 Routing, Layer 2 Switching |
| Firewall - Throughput | 460 MBit/s |
| Power supply | Power consumption operation: 200 W, power consumption including PoE devices: 1280 W, PoE total budget: 1080 W, max. PoE supply per port: 90 W |
| Feature | L3 Tables: ARP Entries: 128,000, IPv4 Routes: 256,000 | L3 Features: DHCP Server (Local Networks), DHCP Relay, Inter-VLAN Routing (Local Networks), Static Routing (Local Networks) | L2 Features: LACP Port Aggregation, STP & RSTP, QoS (DSCP), Pro AV Profiles (Play, Dante, Q-SYS, NDI, SDVoE, Shure, AES67, Crestron), Advanced IGMP Configuration (Querier, Fast Leave, Router Port), IGMP Snooping, 802.1X Control, MAC-Based ACLs & Device IsolationDHCP Snooping & Guarding, Egress Rate Limit, Flow Control, Storm Control, Multicast & Broadcast Rate Limiting, MAC Address Blocking, IP-Based ACLs & Network Isolation, MAC-Based Port Restriction, Port Isolation, Port Mirroring, Jumbo Frames, LLDP-MED, Voice VLAN, Loop Protection |
| More information | LCM Display: 1.3" touchscreen | Housing material: SGCC steel | |
| Notice | UniFi Network: Version 9.1.120 and newer |
| Dimensions | Width: 442mm x Height: 44mm x Depth/Length: 480mm |
| Weight | 8,7 kg |
