EdgeSwitch - 24-250W
EdgeSwitch 24-250W
Please Note
The website is currently being actively developed, you are welcome to place the order and in 99% of the cases your order will be processed as usual, but in some cases there may be a delay or the price may change. We will notify you if there are any issues.
Discontinued
This item was discontinued and currently is not available for order on our website. The item may become available soon. Please contact us if you need more information regarding the upcoming arrivals.
With the Ubiquiti EdgeSwitch 8-150W, networks can be set up or expanded cost-effectively. The Ubiquiti EdgeSwitch 8-150W Switch is a managed PoE+ Gigabit Ethernet switch that offers solid performance and intelligent switching for growing networks. The Ubiquiti EdgeSwitch 8-150W offers a variety of Layer 2 switching features, network protocols, QoS features and has Layer 3 routing options. The EdgeSwitch supports fiber connections via SFP ports with transfer speeds of up to 1 Gbit/s.
| Typ | Switch |
| EAN | 0810354022241 |
| Manufacturer no. | ES-24-250W |
| Connections - Network | RJ-45 24x |
| LEDs | Activity, LAN-Link LEDs: 26x |
| Power supply | Power consumption operation: 30 W, power consumption including PoE devices: 250 W |
| Feature | POE+ IEEE 802.3af/at; Maximal 34,2 W PoE+ oder 17W PoE passiv; ANSI/TIA-1057: LLDP-Media Endpoint Discovery (MED); IEEE 802.1AB: Link Layer Discovery Protocol (LLDP); IEEE 802.1D: Spanning Tree Compatibility; IEEE 802.1S: Multiple Spanning Tree Compatibility; IEEE 802.1W: Rapid Spanning Tree Compatibility; IEEE 802.1Q: Virtual LANs with Port-Based VLANs; IEEE 802.1p: Ethernet Priority with User Provisioning and Mapping; IEEE 802.1X: Port-Based Authentication with Guest VLAN Support; IEEE 802.3: 10BASE-T; IEEE 802.3u: 100BASE-T; IEEE 802.3ab: 1000BASE-T; IEEE 802.1ak: Virtual Bridged Local Area Networks - Amendment 07: Multiple Registration Protocol; IEEE 802.3ac: VLAN Tagging; IEEE 802.3ad: Link Aggregation; IEEE 802.3x: Flow Control; IEEE 802.1D-2004: Generic Attribute Registration Protocol: Clause 12 (G); IEEE 802.1D-2004: Dynamic L2 multicast registration: Clause 10 (GMRP); IEEE 802.1Q-2003: Dynamic VLAN registration: Clause 11.2 (GVRP); RFC 4541: Considerations for Internet Group Management Protocol (IGMP) Snooping Switches; RFC 5171: Unidirectional Link Detection (UDLD) Protocol; Management: Web UI; Industry-Standard CLI; IPv6 Management; Password Management; Autoinstall Support for Firmware Images and Configuration Files; SNMP v1, v2, and v3; SSH 1.5 and 2.0; SSL 3.0 and TLS 1.0; Secure Copy (SCP); Telnet (Multi-Session Support); QoS Features; |
| More information | Zertifikationen: FCC, IC; Layer 2 Switching Features: Broadcast Storm Recovery; Broadcast/Multicast/Unknown Unicast Storm Recovery; DHCP Snooping; IGMP Snooping Querier; Independent VLAN Learning (IVL) Support; Jumbo Ethernet Frame Support; Port MAC Locking; Port Mirroring; Protected Ports; Static MAC Filtering; TACACS+; Voice VLANs; Unauthenticated VLAN; Internal 802.1X Authentication Server; Layer 3 Routing: Static Routing; Policy Based Routing; |
| Dimensions | Width: 485mm x Height: 44mm x Depth/Length: 285mm |
| Weight | 4,7 kg |
