Mini PCIe I/O PCIe Full Size - 4 x Serial RS-232, 1 x Parallel
Delock Mini PCIe module with four RS-232 serial ports and one parallel interface, routed to the outside via the bracket.
Please Note
The website is currently being actively developed, you are welcome to place the order and in 99% of the cases your order will be processed as usual, but in some cases there may be a delay or the price may change. We will notify you if there are any issues.
Discontinued
This item was discontinued and currently is not available for order on our website. The item may become available soon. Please contact us if you need more information regarding the upcoming arrivals.
This Mini PCIe module from Delock gives you four serial and one parallel interface, which you can route to the outside via the slot bracket. You can connect various serial and parallel devices such as printers, scanners, modems, etc. to the adapter.
| EAN | 4043619952793 |
| Manufacturer no. | 95279 |
| slot | Mini-PCIe |
| Connections - external | 1x 25-Pin |
| Feature | Data bits: 5, 6, 7, 8 || Stop bits: 1, 2 || Parity bit: even, odd, none, marked, empty || Flow control: none, hardware RTS / CTS, software XON / XOFF || Signals: DCD, TxD, RxD, RTS, CTS, DTR, DSR, GND, RI |
| More information | 4x 10 pin header connectors |
