PCIe x8 to 2x external USB-X 3.2 Gen 2x2
Delock PCIe card adds two external USB-X ports with USB 3.2 Gen 2x2 for two-port USB expansion (e.g., docking stations).
Please Note
The website is currently being actively developed, you are welcome to place the order and in 99% of the cases your order will be processed as usual, but in some cases there may be a delay or the price may change. We will notify you if there are any issues.
Discontinued
This item was discontinued and currently is not available for order on our website. The item may become available soon. Please contact us if you need more information regarding the upcoming arrivals.
The PCI Express card from Delock expands the PC with two external USB-C 3.2 Gen 2x2 ports. Various USB devices can be connected to the card, such as: B. docking stations, card readers, external housings, etc., can be connected.
| EAN | 4043619890095 |
| Manufacturer no. | 89009 |
| Controller Art | USB 3.2 (20 Gbit/s) |
| Chip | Asmedia ASM3242, ASM1824 |
| Protocol | USB 3.2 Gen 2x2 (20 Gbit/s) |
| Data throughput | 20 GBit/s |
| Connections - external | 2x USB C |
| directly usable devices | 2 |
| Operating System - Supported | Linux, Windows 8, Windows 10 |
| Low Profile | optional |
| Feature | Downward compatible with USB 3.0, USB 2.0, USB 1.1, power supply via PCI Express interface or via the SATA 15 pin, power connection, electrical power per port: max. 15 watts (5 V / 3 A), bootable, supports UASP, supports eXtensible host controller, interface (xHCI) specification 1.1, supports multiple INs |
| Accessories - available | Low profile bezel, instruction manual |
