ASUS PRIME X870-P WIFI AM5 ATX MB DDR5 192GB WiFi7 PCIe5 USB4 (Boxed)
AM5 ATX motherboard w/ DDR5 to 192GB (4xDIMMs), PCIe 5.0 GPU slot, 4x M.2, 2x USB4 40Gbps Type-C, WiFi 7, BT 5.4, 2.5Gb LAN, HDMI 2.1, X870 chipset.
Please Note
The website is currently being actively developed, you are welcome to place the order and in 99% of the cases your order will be processed as usual, but in some cases there may be a delay or the price may change. We will notify you if there are any issues.
Discontinued
This item was discontinued and currently is not available for order on our website. The item may become available soon. Please contact us if you need more information regarding the upcoming arrivals.
| Motherboards - CPU Socket | AMD AM5 |
|---|---|
| Motherboards - Chipset | AMD X870 |
| Motherboards - Form Factor | ATX |
| Motherboards - Memory Type | DDR5 |
| Motherboards - Memory Profile Support | EXPO |
| Motherboards - Memory Slots | 4 |
| Motherboards - Max Memory Capacity | 192 GB |
| Motherboards - Main Slot PCIe Version | PCIe 5.0 |
| Motherboards - Color | Black |
| Motherboards - M.2 Slots | 4 |
| Motherboards - SATA Ports | 2 |
| Motherboards - USB-C Support | Front Panel Type-C header Rear Type-C |
| Motherboards - Wireless Connectivity | Bluetooth WiFi |
The ASUS PRIME X870-P WIFI is a feature-rich AM5 ATX motherboard designed for AMD Ryzen 7000/8000/9000 series processors. Built on the advanced AMD X870 chipset, it supports high-speed DDR5 memory up to 192GB across 4 DIMM slots with overclocking potential to 8000+ MT/s. It features a robust 14+2+1 80A DrMOS VRM for stable power delivery even under heavy loads.
Storage options are extensive with 4x M.2 slots (including PCIe 5.0 support) and 2x SATA III ports supporting RAID 0/1/5/10. Connectivity shines with 2x USB4 Gen2x2 (40Gbps) Type-C rear ports, Wi-Fi 7, Bluetooth 5.4, and 2.5Gb Ethernet. Rear I/O includes HDMI 2.1 and DisplayPort 1.4a for display output. The board offers 1x PCIe 5.0 x16 and 3x PCIe 4.0 x16 slots for expansion.
- ✅ Socket AM5 for latest Ryzen processors
- ✅ DDR5 up to 192GB, 8000+ MT/s (OC)
- ✅ 4x M.2 PCIe slots + 2x SATA III
- ✅ 2x USB4 40Gbps Type-C + WiFi 7
- ✅ 14+2+1 DrMOS VRM, 7x fan headers
- ✅ HDMI 2.1, 2.5Gb LAN, BT 5.4
| Processor manufacturer | AMD |
| Processor socket | Socket AM5 |
| Compatible processor series | AMD Ryzen 7000 Series, AMD Ryzen 8000 Series, AMD Ryzen 9000 Series |
| Motherboard chipset | AMD X870 |
| Motherboard form factor | ATX |
| Supported memory types | DDR5-SDRAM |
| Number of memory slots | 4 |
| Maximum internal memory | 192 GB |
| Supported memory clock speed (max) | 8000 MHz (OC) |
| Number of M.2 (M) slots | 4 |
| Number of SATA III connectors | 2 |
| USB4 Gen 2x2 ports quantity | 2 |
| Ethernet interface type | 2.5 Gigabit Ethernet |
| Top Wi-Fi standard | Wi-Fi 7 (802.11be) |
| Bluetooth version | 5.4 |
| PCI Express x16 (Gen 5.x) slots | 1 |
| PCI Express x16 (Gen 4.x) slots | 3 |
| VRM Phases | 14+2+1 80A DrMOS |
| Number of chassis fan connectors | 7 |
| HDMI version | 2.1 |
| Package width | 353 mm |
| Package depth | 273 mm |
| Package height | 68 mm |
| Weight | 1.56 kg |
