Samsung 990 EVO Plus 4TB M.2 2280 NVMe SSD - PCIe 4.0x4 7250/6300 MB/s MZ-V9S4T0BW (Retail)
4TB Samsung 990 EVO Plus M.2 2280 NVMe SSD—PCIe 4.0 x4/5.0 x2, up to 7,250/6,300 MB/s read/write. Nickel-coated controller, Intelligent TurboWrite 2.0, HMB cache, Samsung Magician support.
Please Note
The website is currently being actively developed, you are welcome to place the order and in 99% of the cases your order will be processed as usual, but in some cases there may be a delay or the price may change. We will notify you if there are any issues.
Discontinued
This item was discontinued and currently is not available for order on our website. The item may become available soon. Please contact us if you need more information regarding the upcoming arrivals.
| Storage (SSD & HDD) - Device Type | Internal SSD |
|---|---|
| Storage (SSD & HDD) - Capacity | 4TB |
| Storage (SSD & HDD) - Interface | PCIe 4.0 (Gen4) |
| Storage (SSD & HDD) - DRAM Cache (SSD) | None (DRAM-less) |
| Storage (SSD & HDD) - Heatsink (SSD) | Not Included |
| Storage (SSD & HDD) - Form Factor | M.2 2280 |
| Storage (SSD & HDD) - PCIe Lanes (SSD) | x4 |
The Samsung 990 EVO Plus MZ-V9S4T0BW is a high-performance 4TB M.2 2280 NVMe SSD designed for gamers, creators, and professionals. It delivers sequential read speeds up to 7,250 MB/s and write speeds up to 6,300 MB/s, powered by PCIe 4.0 x4 (or PCIe 5.0 x2) interface and NVMe 2.0 protocol. Featuring Samsung's in-house 5nm controller with nickel coating for superior thermal efficiency and power consumption (73% better than predecessor), this DRAM-less drive uses Host Memory Buffer (HMB) for optimized caching.
Built with 236-layer V-NAND TLC flash, it supports Intelligent TurboWrite 2.0 with enlarged cache for sustained large-file performance. Security features include AES 256-bit encryption (Class 0), TCG/Opal v2.0, and IEEE 1667. Endurance rated at 2,400 TBW with 1.5 million hours MTBF and 5-year warranty. Compatible with Samsung Magician software for monitoring, optimization, and firmware updates.
- Form Factor: M.2 2280
- Capacity: 4TB
- Random R/W (QD32): 1,050K/1,400K IOPS
- Power (Active): 5.5W Read / 4.8W Write
- Dimensions (bare): 80.15 x 22.15 x 2.38 mm
| Capacity | 4TB |
| Interface | PCIe 4.0 x4 / PCIe 5.0 x2, NVMe 2.0 |
| Form Factor | M.2 2280 |
| Sequential Read | Up to 7,250 MB/s |
| Sequential Write | Up to 6,300 MB/s |
| Random Read (QD32) | 1,050K IOPS |
| Random Write (QD32) | 1,400K IOPS |
| NAND Flash | Samsung V-NAND TLC (236-layer) |
| Controller | Samsung in-house (5nm, nickel-coated) |
| DRAM Cache | None (HMB) |
| Encryption | AES 256-bit (Class 0), TCG/Opal v2.0, IEEE 1667 |
| TBW | 2,400 TBW |
| Power Consumption (Active) | 5.5W / 4.8W (Read/Write) |
| Dimensions | 80.15 x 22.15 x 2.38 mm |
| MTBF | 1.5 Million Hours |
| Warranty | 5 Years |
