Biostar H610MH D5 LGA1700 Micro-ATX Motherboard Intel H610 DDR5 (Boxed)
Micro-ATX Biostar H610MH D5: LGA1700 for 12-14th Gen Intel CPUs, H610 chipset, 2x DDR5 up to 96GB, PCIe 4.0 x16, M.2 PCIe 3.0, HDMI 4K@60Hz, ALC897 audio, GbE LAN for gaming & productivity.
Please Note
The website is currently being actively developed, you are welcome to place the order and in 99% of the cases your order will be processed as usual, but in some cases there may be a delay or the price may change. We will notify you if there are any issues.
Discontinued
This item was discontinued and currently is not available for order on our website. The item may become available soon. Please contact us if you need more information regarding the upcoming arrivals.
| Motherboards - CPU Socket | LGA 1700 |
|---|---|
| Motherboards - Chipset | Intel H610 |
| Motherboards - Form Factor | Micro-ATX |
| Motherboards - Memory Type | DDR5 |
| Motherboards - Memory Slots | 2 |
| Motherboards - Max Memory Capacity | 192 GB |
| Motherboards - Main Slot PCIe Version | PCIe 4.0 |
| Motherboards - Color | Black |
| Motherboards - M.2 Slots | 1 |
| Motherboards - SATA Ports | 4 |
| Motherboards - USB-C Support | None |
| Motherboards - RGB Headers | None |
| Motherboards - Wireless Connectivity | None |
The Biostar H610MH D5 is a reliable Micro-ATX motherboard designed for 12th, 13th, and 14th Generation Intel Core processors using the LGA1700 socket and Intel H610 chipset. It supports dual-channel DDR5 memory up to 96GB across two DIMM slots, with speeds starting at 4800 MT/s, making it suitable for gaming, content creation, and everyday computing.
Key expansion includes a PCIe 4.0 x16 slot for graphics cards, one PCIe 3.0 M.2 slot (32Gb/s) for NVMe SSDs, and four SATA III ports. Connectivity features HDMI supporting 4K@60Hz output, USB 3.2 Gen1 ports, Gigabit Ethernet, and Realtek ALC897 7.1-channel HD audio. The board includes standard rear I/O with VGA, PS/2, and audio jacks.
- ✅ LGA1700 socket: 12th/13th/14th Gen Intel Core, Pentium, Celeron
- ✅ Memory: 2x DDR5, max 96GB (non-ECC, un-buffered)
- ✅ Storage: 1x M.2 PCIe 3.0 x4, 4x SATA 6Gb/s
- ✅ Expansion: 1x PCIe 4.0 x16, 1x PCIe 3.0 x1
- ✅ Video: HDMI 4K@60Hz, VGA
- ✅ Network: Realtek Gigabit Ethernet
- ✅ Audio: Realtek ALC897 7.1-channel
- ✅ No WiFi/BT or RGB headers
- ✅ Accessories: 2x SATA cables, I/O shield, driver DVD, quick guide
| CPU Socket | LGA1700 |
| Chipset | Intel H610 |
| Form Factor | Micro-ATX (244 x 220 mm) |
| Memory Type | DDR5-SDRAM Non-ECC Un-buffered |
| Memory Slots | 2 x DIMM (Dual Channel) |
| Max Memory Capacity | 96 GB |
| Memory Speed | Up to 4800 MT/s |
| PCIe Version (Main) | PCIe 4.0 x16 slot |
| M.2 Slots | 1 x PCIe 3.0 x4 (32Gb/s) |
| SATA Ports | 4 x SATA III 6Gb/s |
| Video Outputs | 1 x HDMI (4K@60Hz), 1 x VGA |
| LAN | 1 x Gigabit Ethernet (Realtek) |
| Audio Codec | Realtek ALC897 7.1-channel HD Audio |
| USB Ports (Rear) | 2 x USB 3.2 Gen1, 4 x USB 2.0 |
| Internal Headers | USB 3.2 Gen1 header, Front USB-C header, COM, TPM |
| BIOS | UEFI BIOS |
| Accessories | 2 x SATA Cables, 1 x I/O Shield, 1 x Driver DVD, 1 x Quick Guide |
| Net Weight | 0.5 kg |
| Supported CPUs | 12th/13th/14th Gen Intel Core, Pentium, Celeron |
| Expansion Slots | 1 x PCIe 4.0 x16, 2 x PCIe 3.0 x1 |
