GIGABYTE Z890 AORUS ELITE WIFI7 LGA1851 ATX Intel Z890 DDR5 WiFi7 (Retail)
GIGABYTE Z890 AORUS ELITE WIFI7: LGA1851 ATX motherboard for Intel Core Ultra Series 2, Z890 chipset, 4x DDR5 up to 256GB, PCIe 5.0 GPU slot, 4x M.2 (1x PCIe5), Wi-Fi 7, 2.5GbE LAN, Thunderbolt 4. DIY-friendly with EZ-Latch.
Please Note
The website is currently being actively developed, you are welcome to place the order and in 99% of the cases your order will be processed as usual, but in some cases there may be a delay or the price may change. We will notify you if there are any issues.
Discontinued
This item was discontinued and currently is not available for order on our website. The item may become available soon. Please contact us if you need more information regarding the upcoming arrivals.
| Motherboards - CPU Socket | LGA 1851 |
|---|---|
| Motherboards - Chipset | Intel Z890 |
| Motherboards - Form Factor | ATX |
| Motherboards - Memory Type | DDR5 |
| Motherboards - Memory Profile Support | XMP |
| Motherboards - Memory Slots | 4 |
| Motherboards - Max Memory Capacity | 256 GB |
| Motherboards - Main Slot PCIe Version | PCIe 5.0 |
| Motherboards - Color | Black |
| Motherboards - M.2 Slots | 4 |
| Motherboards - SATA Ports | 4 |
| Motherboards - USB-C Support | Front Panel Type-C header Rear Type-C |
| Motherboards - Wireless Connectivity | Bluetooth WiFi |
The GIGABYTE Z890 AORUS ELITE WIFI7 is a high-performance ATX motherboard designed for Intel Core Ultra Series 2 processors using the LGA1851 socket and Intel Z890 chipset. It features a robust 16+1+2 phase digital VRM for stable power delivery, supporting dual-channel DDR5 memory up to 256GB across 4 DIMM slots with XMP profiles for overclocking up to 9200MT/s.
Storage and expansion are top-tier with 1x PCIe 5.0 x16 slot for GPUs, 4x M.2 slots (1x PCIe 5.0 x4, 3x PCIe 4.0 x4), 4x SATA 6Gb/s ports, and additional PCIe 4.0 x4 slots. Connectivity includes Wi-Fi 7 (MediaTek MT7925), Bluetooth, 2.5GbE LAN, Thunderbolt 4 Type-C, front USB-C 10Gb/s, multiple USB ports, and Sensor Panel Link for diagnostics. Premium features like VRM Thermal Armor, M.2 Thermal Guard, EZ-Latch for PCIe/M.2, and WIFI EZ-Plug enhance user experience.
- ✅ LGA1851 socket for Intel Core Ultra (Series 2)
- ✅ 4x DDR5 DIMMs, max 256GB, XMP support
- ✅ PCIe 5.0 x16 GPU slot + 4x M.2 (PCIe 5.0/4.0)
- ✅ Wi-Fi 7, 2.5GbE, Thunderbolt 4, USB-C 10Gbps
- ✅ EZ-Latch, Q-Flash, AI Perfdrive BIOS
| CPU Socket | LGA1851 (Intel Core Ultra Series 2) |
| Chipset | Intel Z890 |
| Form Factor | ATX (30.5 x 24.4 cm) |
| Memory Type | DDR5 Dual Channel |
| Memory Slots | 4 x DIMM, up to 256GB (64GB single) |
| Max Memory Speed | Up to 9200(O.C.) MT/s, XMP support |
| PCIe Slots | 1 x PCIe 5.0 x16 (CPU), 2 x PCIe 4.0 x4 (Chipset) |
| M.2 Slots | 4 (1 x PCIe 5.0 x4, 3 x PCIe 4.0 x4) |
| SATA Ports | 4 x SATA 6Gb/s |
| LAN | Realtek 2.5GbE |
| Wireless | Wi-Fi 7 MT7925 (802.11be), Bluetooth |
| USB Rear | 4 x USB 2.0, 2 x USB 3.2 Gen2, 3 x USB 3.2 Gen1, Thunderbolt 4 Type-C |
| USB Front | 1 x USB-C 10Gb/s, 1 x Sensor Panel Link |
| VRM | 16+1+2 phases Digital VRM |
| Audio | High-End Audio Capacitor |
| BIOS | AMI UEFI BIOS, Q-Flash, HyperTune AI |
| MPN | Z890 AORUS ELITE WIFI7 / Z890AORELWF7 |
