Samsung 870 EVO 500GB SSD - MZ-77E500B - 2.5-inch SATA III 6Gb/s, 560/530 MB/s (Boxed)
Samsung 870 EVO 500GB 2.5-inch SSD (MZ-77E500B). SATA III 6Gb/s interface with up to 560/530 MB/s speeds. Uses 128L 3D V-NAND TLC, Intelligent TurboWrite, 240 TBW endurance. 5-year warranty, ideal for desktops/laptops.
Please Note
The website is currently being actively developed, you are welcome to place the order and in 99% of the cases your order will be processed as usual, but in some cases there may be a delay or the price may change. We will notify you if there are any issues.
Discontinued
This item was discontinued and currently is not available for order on our website. The item may become available soon. Please contact us if you need more information regarding the upcoming arrivals.
| Storage (SSD & HDD) - Device Type | Internal SSD |
|---|---|
| Storage (SSD & HDD) - Capacity | 256GB - 512GB |
| Storage (SSD & HDD) - Sequential Read Speed (SSD) | Up to 550 MB s |
| Storage (SSD & HDD) - Interface | SATA III |
| Storage (SSD & HDD) - DRAM Cache (SSD) | Yes |
| Storage (SSD & HDD) - Heatsink (SSD) | Not Included |
| Storage (SSD & HDD) - Form Factor | 2.5 inch |
| Storage (SSD & HDD) - PCIe Lanes (SSD) | Not Specified |
The Samsung 870 EVO 500GB SSD (MZ-77E500B) is a high-performance 2.5-inch SATA III drive designed for reliable everyday computing. It delivers sequential read/write speeds up to 560/530 MB/s and random performance up to 98,000/88,000 IOPS, maximizing SATA limits with Samsung's 128-layer V-NAND TLC and MKX controller with DRAM cache.
Featuring Intelligent TurboWrite technology for sustained writes (42GB Turbo region for 500GB model), AES 256-bit encryption, and 240 TBW endurance rating. Backed by a 5-year warranty and 1.5 million hours MTBF, it's perfect for OS boot drives, gaming, or general storage upgrades in PCs and laptops.
- SATA III 6Gb/s interface, backward compatible
- Dimensions: 100 x 69.85 x 6.8 mm
- Power: Idle 30mW, Active ~2.0-2.2W
- Includes Samsung Magician software for optimization
- Shock resistant: 1500G non-operating
| Capacity | 500GB |
| Form Factor | 2.5 inch |
| Interface | SATA III 6Gb/s |
| NAND Type | Samsung 128L 3D V-NAND TLC |
| DRAM Cache | Yes |
| Sequential Read | Up to 560 MB/s |
| Sequential Write | Up to 530 MB/s |
| Random Read (QD32) | Up to 98,000 IOPS |
| Random Write (QD32) | Up to 88,000 IOPS |
| Endurance (TBW) | 240 TB |
| Power Consumption (Idle) | 30 mW |
| Power Consumption (Active R/W) | 2.0W / 2.2W |
| MTBF | 1.5 million hours |
| Warranty | 5 years |
| Dimensions (W x D x H) | 100 x 69.85 x 6.8 mm |
| Weight (Device) | 45 g (max) |
| Encryption | AES 256-bit |
