Kingston NV3 4TB M.2 NVMe SSD - PCIe Gen4 x4 6000/5000 MB/s - SNV3S/4000G (Boxed)
Kingston NV3 4TB M.2 NVMe SSD (SNV3S/4000G) — PCIe Gen4 x4, up to 6,000/5,000 MB/s read/write, single-sided M.2 2280 for laptops, ultrabooks and small-form-factor PCs. DRAM-less design with 1280TB endurance and low power consumption.
Please Note
The website is currently being actively developed, you are welcome to place the order and in 99% of the cases your order will be processed as usual, but in some cases there may be a delay or the price may change. We will notify you if there are any issues.
Discontinued
This item was discontinued and currently is not available for order on our website. The item may become available soon. Please contact us if you need more information regarding the upcoming arrivals.
| Storage (SSD & HDD) - Device Type | Internal SSD |
|---|---|
| Storage (SSD & HDD) - Capacity | 4TB |
| Storage (SSD & HDD) - Sequential Read Speed (SSD) | 5001 to 7000 MB s |
| Storage (SSD & HDD) - DRAM Cache (SSD) | None (DRAM-less) |
| Storage (SSD & HDD) - Interface | PCIe 4.0 (Gen4) |
| Storage (SSD & HDD) - Heatsink (SSD) | Not Included |
| Storage (SSD & HDD) - Form Factor | M.2 2280 |
| Storage (SSD & HDD) - PCIe Lanes (SSD) | x4 |
For high-speed, low-power storage needs
Kingston’s NV3 PCIe 4.0 NVMe SSDs are next-gen storage solutions powered by a Gen 4x4 NVMe controller, delivering read/write speeds of up to 6,000/5,000MB/s. The compact, single-sided M.2 2280 (22x80mm) design expands storage in small-form-factor systems like laptops, ultrabooks and handheld gaming devices. It offers lower power consumption and reduced heat, optimising your system's performance without compromising value. Available in capacities up to 4TB to store applications, documents, photos, videos, games and more.
Gen 4x4 NVMe PCIe performance
Upgrade your system with read/write speeds up to 6,000/5,000MB/s. This DRAM-less SSD uses Host Memory Buffer (HMB) for efficient operation while maintaining high performance. Ideal for thin laptops, small PCs and gaming handhelds with M.2 connectors.
- PCIe 4.0 x4 NVMe interface for maximum bandwidth
- 3D NAND flash with 1280TB endurance (TBW)
- MTBF 2,000,000 hours for reliability
- Low power and heat for better battery life
- Single-sided design conserves space
- 3-5 year warranty with technical support
| SSD capacity | 4 TB |
| SSD form factor | M.2 |
| Interface | PCI Express 4.0 |
| NVMe | Yes |
| Memory type | 3D NAND |
| Component for | PC/Laptop |
| M.2 SSD size | 2280 (22 x 80 mm) |
| Read speed | 6000 MB/s |
| Write speed | 5000 MB/s |
| Mean time between failures (MTBF) | 2000000 h |
| TBW rating | 1280 TB |
| DRAM Cache | None (DRAM-less) |
| Width | 22 mm |
| Depth | 80 mm |
| Height | 2.3 mm |
| Weight | 7 g |
| Package width | 129.5 mm |
| Package depth | 8.38 mm |
| Package height | 184.2 mm |
| Package weight | 30.41 g |
| Operating temperature (T-T) | 0 - 70 °C |
| Storage temperature (T-T) | -40 - 85 °C |
| Operating vibration | 10 G |
| Endurance (Total Bytes Written) | 1280TB |
| NAND Type | 3D |
| PCIe Lanes | x4 |
