GIGABYTE Z890 AORUS ELITE WIFI7 ICE LGA1851 ATX Z890 DDR5 (Retail)
ATX motherboard with LGA1851 socket, Intel Z890 chipset. Supports DDR5 up to 256GB, PCIe 5.0 x16, 4x M.2 slots, Wi-Fi 7, 2.5GbE LAN. White ICE design with 16+1+2 VRM for Core Ultra Series 2 CPUs.
Please Note
The website is currently being actively developed, you are welcome to place the order and in 99% of the cases your order will be processed as usual, but in some cases there may be a delay or the price may change. We will notify you if there are any issues.
Discontinued
This item was discontinued and currently is not available for order on our website. The item may become available soon. Please contact us if you need more information regarding the upcoming arrivals.
| Motherboards - CPU Socket | LGA 1851 |
|---|---|
| Motherboards - Chipset | Intel Z890 |
| Motherboards - Form Factor | ATX |
| Motherboards - Memory Type | DDR5 |
| Motherboards - Memory Profile Support | XMP |
| Motherboards - Memory Slots | 4 |
| Motherboards - Max Memory Capacity | 256 GB |
| Motherboards - Main Slot PCIe Version | PCIe 5.0 |
| Motherboards - Color | White |
| Motherboards - M.2 Slots | 4 |
| Motherboards - SATA Ports | 4 |
| Motherboards - USB-C Support | Front Panel Type-C header Rear Type-C |
| Motherboards - RGB Headers | 3-pin 5V ARGB |
| Motherboards - Wireless Connectivity | Bluetooth WiFi |
The GIGABYTE Z890 AORUS ELITE WIFI7 ICE is a premium ATX motherboard designed for Intel Core Ultra Series 2 processors with LGA 1851 socket and Z890 chipset. Featuring a robust 16+1+2 twin digital VRM design with 80A Smart Power Stage, it delivers stable power for high-performance gaming and content creation.
This white 'ICE' variant offers four DDR5 DIMM slots supporting up to 256GB (64GB per DIMM) with XMP profiles and speeds up to 8800MT/s (OC). Storage includes 4x M.2 slots (1x PCIe 5.0 x4, 3x PCIe 4.0 x4) and 4x SATA ports. Expansion features PCIe 5.0 x16 slot for graphics cards plus PCIe 4.0 x4 slots. Connectivity shines with Wi-Fi 7, 2.5GbE LAN, Thunderbolt 4, front USB-C, and multiple USB ports including rear Type-C.
- ✅ LGA 1851 socket for Intel Core Ultra 200S Series
- ✅ 4x DDR5 DIMM up to 256GB, XMP support
- ✅ 1x PCIe 5.0 x16 + 4x M.2 (PCIe 5.0/4.0)
- ✅ Wi-Fi 7, 2.5GbE LAN, Thunderbolt 4
- ✅ EZ-Latch design, VRM Thermal Armor, M.2 Thermal Guard
- ✅ 16+1+2 phases VRM, AI Perfdrive BIOS
| CPU Socket | LGA 1851 |
| Chipset | Intel Z890 |
| Form Factor | ATX |
| Memory Type | DDR5 |
| Memory Slots | 4x DIMM |
| Max Memory | 256 GB (64GB single DIMM) |
| VRM Design | 16+1+2 Twin Digital VRM, 80A Smart Power Stage |
| PCIe Slots | 1x PCIe 5.0 x16, 2x PCIe 4.0 x4 |
| M.2 Slots | 4 (1x PCIe 5.0 x4, 3x PCIe 4.0 x4) |
| SATA Ports | 4x SATA |
| LAN | 2.5GbE |
| Wireless | Wi-Fi 7 (802.11be), Bluetooth |
| USB | Rear USB-C, Front USB-C header, Thunderbolt 4 |
| Memory Speed | Up to 8800MT/s (OC), XMP support |
| Color | Snow White (ICE) |
| Cooling | VRM Thermal Armor, M.2 Thermal Guard |
