24-Port Ethernet PoE+ injektor 370W, Switch
The Digitus DN-95117 is a 24 port 10G PoE+ mid-span hub (PoE injector). It offers 24 input ports for data and 24 output ports that provide data and PoE. Each PoE port supports conn...
Please Note
The website is currently being actively developed, you are welcome to place the order and in 99% of the cases your order will be processed as usual, but in some cases there may be a delay or the price may change. We will notify you if there are any issues.
Discontinued
This item was discontinued and currently is not available for order on our website. The item may become available soon. Please contact us if you need more information regarding the upcoming arrivals.
The Digitus DN-95117 is a 24 port 10G PoE+ mid-span hub (PoE injector). It offers 24 input ports for data and 24 output ports that provide data and PoE. Each PoE port supports connected devices according to the PoE standard IEEE802.3af and IEEE802.3at with 15.4 watts or 30 watts, such as PoE access points, PoE IP phones or PoE IP cameras. The switch provides a maximum budget of 370 watts for all ports and a maximum budget of 30 watts per port.
| Typ | Switch |
| Color | schwarz |
| EAN | 4016032430384 |
| Manufacturer no. | DN-95117 |
| Design | Rack |
| Area of application | Business |
| Connections - Network | RJ-45 24x (of which: 24x 100/1000/10000) |
| Routing & Switching - Layer | Layer 2 Switching |
| Power supply | Power consumption operation: 20 W, PoE total budget: 370 W, max. PoE supply per port: 30 W |
| Feature | IEEE802.3, IEEE802.3u, IEEE802.3ab, IEEE802.3af, IEEE802.3at |
| Dimensions | Width: 440mm x Height: 45mm x Depth/Length: 345mm |
| Warnings and safety information | Safety Instructions:This product is for indoor use only. Read all instructions and follow all warnings and instructions on the device. Do not place this device on an unstable surface (such as cart, stand, table, etc.). Do not use this device near water. Do not place this device near or above a radiator. The housing is provided with openings for heat dissipation and ventilation. To avoid overheating during operation, the ventilation openings must not be blocked or covered. Do not place the device on a soft surface (e.g. bed, sofa, blanket, etc.). This blocks the ventilation. The device must not be installed in an enclosed environment if adequate ventilation is not ensured. Do not spray liquids onto the device. Before cleaning, unplug the power plug. Do not use liquid or foam cleaners. Clean the device with a damp cloth. Connect the device according to the power supply on the nameplate. To avoid damage to the device, it is important that all devices are properly grounded. Do not place any objects on the power cord and route it to avoid a tripping hazard. Use a surge protector, regulator, or uninterruptible power supply (UPS) to protect your system from sudden, transient, and reduced power. Secure the system cable and power cable properly and ensure that no objects press on the cable. Do not insert any objects into the device through the openings in the housing. There is a risk of a short circuit, which could result in fire or electric shock. Do not attempt to repair the device yourself. Always contact an authorized customer service center. If any of the following conditions occur, unplug the device and send the device to an authorized service center for repair The power cord, power adapter, or power plug is damaged or worn; Liquid has entered the device; The device was exposed to rain or water; The device has been dropped or the casing has been damaged; The function of the device is obviously changed; The device cannot be operated as described in the operating instructions. |
