Gigabyte X870E AORUS XTREME AI TOP AM5 E-ATX MB DDR5 PCIe5 WiFi7 (Boxed)
High-end Gigabyte X870E AORUS XTREME AI TOP AM5 E-ATX motherboard: DDR5 to 256GB/8800MT/s OC, 4x M.2 (1x PCIe5), PCIe5 GPU, dual 10GbE, Wi-Fi7, USB4, 18+2+2 VRM, AI tuning.
Please Note
The website is currently being actively developed, you are welcome to place the order and in 99% of the cases your order will be processed as usual, but in some cases there may be a delay or the price may change. We will notify you if there are any issues.
Discontinued
This item was discontinued and currently is not available for order on our website. The item may become available soon. Please contact us if you need more information regarding the upcoming arrivals.
| Motherboards - CPU Socket | AMD AM5 |
|---|---|
| Motherboards - Chipset | AMD X870E |
| Motherboards - Form Factor | E-ATX |
| Motherboards - Memory Type | DDR5 |
| Motherboards - Memory Profile Support | EXPO XMP |
| Motherboards - Memory Slots | 4 |
| Motherboards - Max Memory Capacity | 256 GB |
| Motherboards - Main Slot PCIe Version | PCIe 5.0 |
| Motherboards - Color | Black |
| Motherboards - M.2 Slots | 4 |
| Motherboards - SATA Ports | 4 |
| Motherboards - USB-C Support | Rear Type-C |
| Motherboards - RGB Headers | 3-pin 5V ARGB 4-pin 12V RGB |
| Motherboards - Wireless Connectivity | Bluetooth WiFi |
Elevate your build with the GIGABYTE X870E AORUS XTREME AI TOP, a premium AM5 E-ATX motherboard designed for AMD Ryzen 7000/8000/9000 series processors. Featuring an 18+2+2 phase digital VRM with 110A Smart Power Stages, it delivers rock-solid power for extreme overclocking and AI workloads. AI-enhanced HyperTune BIOS optimizes performance with over 95% accuracy, pushing DDR5 memory up to 8800MT/s OC via AMD EXPO and Intel XMP support.
Connectivity is unmatched with dual 10GbE LAN (Marvell AQtion), Wi-Fi 7 (Qualcomm), Bluetooth 5.3, and dual USB4 Type-C ports (40Gbps + DP-Alt). Storage includes 4x M.2 slots (1x PCIe 5.0 x4, 3x PCIe 4.0 x4) plus 4x SATA III with RAID 0/1/10. Expansion offers 2x PCIe 5.0 x16 (titanium-reinforced) and premium Realtek ALC1220 7.1 audio.
- ✅ 4x DDR5 DIMM slots, dual-channel up to 256GB (64GB/slot), ECC support
- ✅ 8x chassis fan + 5x pump headers, VRM Thermal Armor, M.2 Thermal Guard
- ✅ PCIe 5.0 GPU slot, USB3.2 Gen2 abundance, front QC 65W USB-C
- ✅ EZ-Latch DIY features, Sensor Panel Link, 3-year warranty (some regions 5yr)
| Processor manufacturer | AMD |
| Processor socket | Socket AM5 |
| Compatible processor series | AMD Ryzen 7000 Series, AMD Ryzen 8000 Series, AMD Ryzen 9000 Series |
| Motherboard chipset | AMD X870E |
| Motherboard form factor | Extended ATX |
| Supported memory types | DDR5-SDRAM |
| Number of memory slots | 4 |
| Memory channels | Dual-channel |
| ECC сompatibility | ECC & Non-ECC |
| Supported memory clock speeds | 8800, 8600, 8400, 8266, 8200, 8000, 7950, 7900, 7800, 7600, 7400, 7200, 7000, 6800, 6600, 6400, 6200, 6000, 5800, 5600, 5200, 4800, 4400 MHz (O.C.) |
| Supported memory clock speed (max) | 8800 MHz (O.C.) |
| Maximum internal memory | 256 GB |
| Maximum internal memory per slot | 64 GB |
| Number of M.2 (M) slots | 4 |
| 1st M.2 highest PCI Express generation | 5.0 |
| 2nd M.2 highest PCI Express generation | 4.0 |
| 3rd M.2 highest PCI Express generation | 4.0 |
| 4th M.2 highest PCI Express generation | 4.0 |
| Number of SATA III connectors | 4 |
| PCI Express x16 (Gen 5.x) slots | 2 |
| PCI Express x16 (Gen 4.x) slots | 1 |
| USB4 Gen 2x2 ports quantity | 2 |
| Ethernet LAN (RJ-45) ports | 2 |
| Ethernet interface type | 10 Gigabit Ethernet |
| Wi-Fi | Yes |
| Top Wi-Fi standard | Wi-Fi 7 (802.11be) |
| Bluetooth | Yes |
| Bluetooth version | 5.3 |
| Audio chip | Realtek ALC1220 |
| Audio output channels | 7.1 channels |
| Product colour | Black |
| Width | 305 mm |
| Depth | 269 mm |
| Height | 35 mm |
| Weight | 3.76 kg |
| Warranty period | 3 year(s) |
| Memory Profile Support | AMD EXPO, XMP |
| VRM Design | 18+2+2 Twin Digital VRM, 110A SPS |
