Sparkle Intel Arc B570 GUARDIAN OC 10GB GDDR6 PCIe 4.0 (Boxed)
Sparkle Intel Arc B570 GUARDIAN OC 10GB GDDR6 graphics card with dual-fan cooling, PCIe 4.0 x8, DisplayPort 2.1, HDMI 2.1, Intel XeSS AI upscaling, ray tracing, and 8K media support.
Please Note
The website is currently being actively developed, you are welcome to place the order and in 99% of the cases your order will be processed as usual, but in some cases there may be a delay or the price may change. We will notify you if there are any issues.
Discontinued
This item was discontinued and currently is not available for order on our website. The item may become available soon. Please contact us if you need more information regarding the upcoming arrivals.
| GPU (Graphics Cards) - Series | Intel Arc |
|---|---|
| GPU (Graphics Cards) - PCIe Interface | PCIe 4.0 x8 |
| GPU (Graphics Cards) - Cooler Type | Dual Fan |
| GPU (Graphics Cards) - Color | Black |
| GPU (Graphics Cards) - Backplate | Yes |
| GPU (Graphics Cards) - VRAM Capacity | 10 GB |
| GPU (Graphics Cards) - VRAM Type | GDDR6 |
| GPU (Graphics Cards) - Outputs | DisplayPort 2.1 HDMI 2.1 |
| GPU (Graphics Cards) - Power Connector | None |
The Sparkle Intel Arc B570 GUARDIAN OC is a high-performance graphics card designed for gaming and content creation. Featuring 10GB of GDDR6 memory on a 160-bit bus, this card delivers excellent performance for 1440p and 4K gaming with support for Intel XeSS AI upscaling technology. The card supports ray tracing for enhanced visual fidelity and can handle 8K media playback, making it versatile for both entertainment and professional workflows.
Built with the TORN 2.0 cooling system featuring dual customized AXL fans, the B570 maintains optimal temperatures during intensive workloads. The compact 2.2-slot design fits most modern PC cases, while the full-metal backplate provides structural rigidity and improved heat dissipation. With PCIe 4.0 x8 connectivity and a maximum resolution of 7680 x 4320, this card offers modern connectivity through DisplayPort 2.1 and HDMI 2.1 outputs. The card includes Intel AI Playground support for accelerated AI features in creation and editing applications, and features an elegant blue breathing light effect for gaming aesthetics.
Technical highlights include a 150W TDP, 2500 MHz core clock, and 19000 MHz memory clock. The card supports DirectX 12 and OpenGL 4.6, ensuring compatibility with modern games and applications. A 1-year limited warranty on parts and labor is included with this retail boxed version.
- 10GB GDDR6 160-bit memory
- PCIe 4.0 x8 interface
- Dual-fan TORN 2.0 cooling system
- DisplayPort 2.1 and HDMI 2.1 outputs
- Intel XeSS AI upscaling and ray tracing support
- 8K media playback capability
- 150W maximum power consumption
- Full-metal backplate with 2.2-slot design
| GPU Memory | 10GB GDDR6 |
| Memory Bus Width | 160-bit |
| Memory Clock | 19000 MHz |
| Core Clock | 2500 MHz |
| PCIe Interface | PCIe 4.0 x8 |
| Maximum Resolution | 7680 x 4320 |
| DirectX Support | DirectX 12 |
| OpenGL Support | OpenGL 4.6 |
| Maximum TDP | 150W |
| Cooling System | TORN 2.0 Dual-Fan with AXL Fans |
| Card Design | 2.2-slot, Full Height |
| Backplate | Full-Metal |
| Video Outputs | DisplayPort 2.1, HDMI 2.1 |
| Power Connectors | None (PCIe slot powered) |
| Features | Intel XeSS AI Upscaling, Ray Tracing, 8K Media Support, Intel AI Playground, Blue Breathing Light Effect |
| Warranty | 1 Year Limited (Parts and Labor) |
| Manufacturer Part Number | SB570G-10GOC |
