600W DeepCool PF600X 80 Plus Bronze ATX
DeepCool PF600X. 600 W. 200 - 240 V. 50/60 Hz. 5 A. Aktiv. 100 W
Please Note
The website is currently being actively developed, you are welcome to place the order and in 99% of the cases your order will be processed as usual, but in some cases there may be a delay or the price may change. We will notify you if there are any issues.
Discontinued
This item was discontinued and currently is not available for order on our website. The item may become available soon. Please contact us if you need more information regarding the upcoming arrivals.
DeepCool PF600X. Gesamtleistung: 600 W. AC Eingangsspannung: 200 - 240 V. AC Eingangsfrequenz: 50/60 Hz. Motherboard Anschlussstecker: 20+4 pin ATX. Stromkabellänge Motherboard: 55 cm. SATA-Netzkabellänge: 450.600.750 mm. Zweck: PC. Stromversorgungseinheit (PSU) Formfaktor: ATX. 80 Plus Zertifizierung: 80 PLUS Bronze. Produktfarbe: Schwarz. Kühlung: Aktiv. Lüfterdurchmesser: 12 cm. Mitgelieferte Kabel: AC
| Gesamtleistung | 600 W |
| AC Eingangsspannung | 200 - 240 V |
| AC Eingangsfrequenz | 50/60 Hz |
| Eingangsstrom | 5 A |
| Leistungsfaktorkorrekturfilter (PFC) | Aktiv |
| Kombinierter Strom (+3.3V) | 100 W |
| Kombinierter Strom (+12V) | 600 W |
| Kombinierter Strom (+5V) | 100 W |
| Kombinierter Strom (-12V) | 3.6 W |
| Kombinierter Strom (+5Vsb) | 15 W |
| Max. Ausgangsstrom (+3.3V) | 16 A |
| Max. Ausgangsstrom (+12V) | 50 A |
| Max Ausgangsstrom (+5V) | 16 A |
| Max. Ausgangsstrom (-12V) | 0.3 A |
| Max. Ausgangsstrom (+5Vsb) | 3 A |
| Haltezeit | 16 ms |
| Effizienz | 88% |
| Energieschutzeigenschaften | No load operation. Überstrom. Überlastung. Überspannung. Überhitzung. Kurzschluß. Surge & inrush protection (SIP). Unterspannung |
| Motherboard Anschlussstecker | 20+4 pin ATX |
| Stromkabellänge Motherboard | 55 cm |
| Anzahl SATA Stromstecker | 3 |
| SATA-Netzkabellänge | 450.600.750 mm |
| Anzahl der SATA-Stromkabel | 2 |
| Anzahl Molex Anschlüsse 4pin | 1 |
| Periphere (Molex) Netzkabellänge | 900 mm |
| Anzahl PCI Express Stromstecker 6+2pin | 2 |
| PCI Express Netzkabellänge | 55 cm |
| Feature | Kabelbinder inklusive |
| CPU-Leistung Kabellänge | 62 cm |
| Kabeltyp | Nicht-modular |
| 80 Plus Zertifizierung | 80 PLUS Bronze |
| Zweck | PC |
| Stromversorgungseinheit (PSU) Formfaktor | ATX |
| ATX-Version | 2.52 |
| Lagertyp | HYB |
| Mittlere Betriebsdauer zwischen Ausfällen (MTBF) | 40000 h |
| Produktfarbe | Schwarz |
| Kühlung | Aktiv |
| Lüfterdurchmesser | 12 cm |
| Anzahl Lüfter | 1 Lüfter |
| Lüfterplatzierung | Oben |
| Betriebstemperatur | 0 - 40 °C |
| Mitgelieferte Kabel | AC |
| Konformitätsbescheinigungen | CCC. CE. KC. RCM. TÜV mark. WEEE |
| Breite | 150 mm |
| Tiefe | 140 mm |
| Höhe | 86 mm |
| Verpackungsart | Box |
| Nachhaltigkeitszertifikate | ErP. Triman |
| Garantiezeit | 3 Jahr(e) |
