ASUS PRIME 850W - 90YE00U0-B0NA00 - Fully-Modular, 80 PLUS Gold, ATX, 8-Year Warranty
850W fully modular ATX 3.1 PSU with 80 PLUS Gold efficiency (up to 92%), dual ball-bearing fan, 16-pin PCIe Gen 5 cable, 3x 8-pin PCIe, black/white sides, and 8-year warranty for gaming rigs.
Please Note
The website is currently being actively developed, you are welcome to place the order and in 99% of the cases your order will be processed as usual, but in some cases there may be a delay or the price may change. We will notify you if there are any issues.
Discontinued
This item was discontinued and currently is not available for order on our website. The item may become available soon. Please contact us if you need more information regarding the upcoming arrivals.
| PSU (Power Supplies) - Wattage | 800 - 899 W |
|---|---|
| PSU (Power Supplies) - Efficiency Rating | 80 Plus Gold |
| PSU (Power Supplies) - Color | Black White |
| PSU (Power Supplies) - Modularity | Fully modular |
| PSU (Power Supplies) - PCIe GPU Connectors | 1x 12VHPWR 16-pin 3x 8/6 pins |
| PSU (Power Supplies) - Length | 141-160 mm |
| PSU (Power Supplies) - EPS CPU Connectors | 1x 4+4pin EPS/ATX12V |
Prime Performance
The ASUS Prime 850W Gold PSU delivers efficient, reliable power for high-performance workstations, all-round PCs, and gaming systems. Certified 80 PLUS Gold with up to 92% efficiency, it uses low-ESR capacitors for reduced heat and noise. Fully modular design with flat cables simplifies cable management.
Features ATX 3.1 compliance and includes a native 16-pin PCIe cable for Gen 5 graphics cards, plus 3x 8-pin PCIe connectors for broad GPU compatibility. Dual ball-bearing 135mm fan lasts 80,000 hours with minimal noise. Unique black/white housing lets you match your build theme. Backed by an 8-year warranty.
- ✅ 80 PLUS Gold certified (92%+ efficiency)
- ✅ Fully modular with all key cables included
- ✅ 1x 16-pin PCIe + 3x 8-pin PCIe connectors
- ✅ Dual ball-bearing fan for durability
- ✅ ATX 3.1 & PCIe Gen 5.1 compatible
- ✅ 8-year ASUS warranty
| Total power | 850 W |
| AC input voltage | 100 - 240 V |
| Power Factor Correction (PFC) type | Active |
| Combined power (+3.3V) | 110 W |
| Combined power (+12V) | 846 W |
| Combined power (+5V) | 110 W |
| Combined power (-12V) | 3.6 W |
| Combined power (+5Vsb) | 12.5 W |
| Max output current (+3.3V) | 20 A |
| Max output current (+12V) | 70.5 A |
| Max output current (+5V) | 20 A |
| Max output current (-12V) | 0.3 A |
| Max output current (+5Vsb) | 2.5 A |
| Power protection features | Over current, Over power, Over voltage, Overheating, Short circuit, Under voltage |
| Motherboard power connector | 20+4 pin ATX |
| Motherboard power cable length | 61 cm |
| Number of SATA power connectors | 5 |
| SATA power cable length | 400, 120 mm |
| Peripheral (Molex) power connectors (4-pin) | 3 |
| Peripheral (Molex) power cable length | 400, 150 mm |
| PCI Express power connectors (8-pin) | 3 |
| PCI Express power connectors (16-pin) | 1 |
| PCI Express power cable length | 67.5 cm |
| CPU power connector (4+4 pin) | Yes |
| CPU power cable length | 65 cm |
| Cabling type | Fully-Modular |
| 80 PLUS certification | 80 PLUS Gold |
| Purpose | PC |
| Power supply unit (PSU) form factor | ATX |
| ATX version | 3.0 |
| Mean time between failures (MTBF) | 120000 h |
| Product colour | Black, White |
| Cooling type | Active |
| Number of fans | 1 fan(s) |
| Fan location | Top |
| Fan diameter | 135 mm |
| Illumination | No |
| Cables included | CPU, PCIe, SATA, Peripheral (Molex) |
| Compliance certificates | RoHS |
| Width | 150 mm |
| Depth | 150 mm |
| Height | 86 mm |
| Weight | 1.5 kg |
| Package width | 346 mm |
| Package depth | 208 mm |
| Package height | 144 mm |
| Package weight | 2.92 kg |
| Package type | Box |
| Bearing technology | Dual ball bearing |
