Eaton 9SX 1500I USV Tower Online 1350 W 1500 VA Eingang C14 Ausgang 6x C13
Eaton 9SX. Doppelwandler (Online). 1.5 kVA. 1350 W. Reiner Sinus. 190 V. 276 V
Please Note
The website is currently being actively developed, you are welcome to place the order and in 99% of the cases your order will be processed as usual, but in some cases there may be a delay or the price may change. We will notify you if there are any issues.
Discontinued
This item was discontinued and currently is not available for order on our website. The item may become available soon. Please contact us if you need more information regarding the upcoming arrivals.
Eaton 9SX. USV-Topologie: Doppelwandler (Online). Ausgangskapazität: 1.5 kVA. Ausgangsleistung: 1350 W. AC-Steckertypen: C13-Koppler. Stecker: C14-Koppler. Anzahl der AC-Ausgänge: 6 AC-Ausgänge. Akku-/Batterietechnologie: Plombierte Bleisäure (VRLA). Typische Backup-Zeit bei halber Belastung: 16 min. Formfaktor: Tower. Produktfarbe: Schwarz. Display-Typ: LCD. Zertifizierung: IEC/EN 62040-1. UL 1778. CSA 22.2. IEC/EN 62040 -2 . FCC Class B. CISPR22 Class B. CE /CB report...
| USV-Topologie | Doppelwandler (Online) |
| Ausgangskapazität | 1.5 kVA |
| Ausgangsleistung | 1350 W |
| Wellenform | Reiner Sinus |
| Eingangs-Betriebsspannung (min) | 190 V |
| Eingangs-Betriebsspannung (max) | 276 V |
| Eingangsfrequenz | 40/70 Hz |
| Ausgangs-Betriebsspannung (min) | 200 V |
| Ausgangs-Betriebsspannung (max) | 240 V |
| Output Frequenz | 50/60 Hz |
| Anzahl der Eingangs-Phasen | 1 |
| Anzahl der Ausgangs-Phasen | 1 |
| Leistungsfaktor | 0.9 |
| Geräuschpegel | 43 dB |
| AC-Steckertypen | C13-Koppler |
| Stecker | C14-Koppler |
| Anzahl der AC-Ausgänge | 6 AC-Ausgänge |
| Feature | Automatischer Batterietest |
| Anzahl USB 2.0 Anschlüsse | 1 |
| Serielle Schnittstelle | RS-232 |
| RS-232 port | 1 |
| Akku-/Batterietechnologie | Plombierte Bleisäure (VRLA) |
| Typische Backup-Zeit bei halber Belastung | 16 min |
| Formfaktor | Tower |
| Produktfarbe | Schwarz |
| Display-Typ | LCD |
| Betriebstemperatur | 0 - 40 °C |
| Zertifizierung | IEC/EN 62040-1. UL 1778. CSA 22.2. IEC/EN 62040 -2 . FCC Class B. CISPR22 Class B. CE /CB report (TUV) / cULus / EAC / RCM / BIS / KCC |
| Sicherheit | IEC/EN 62040-1. UL 1778. CSA 22.2 |
| Breite | 160 mm |
| Tiefe | 437 mm |
| Höhe | 252 mm |
| Gewicht | 24.5 kg |
| Mitgelieferte Software | Intelligent Power Software suite |
| Warentarifnummer (HS) | 85078000 |
| Eingang Verbindungstyp | IEC C14 |
| Nominale Ausgang Spannung | 230 V |
| Nominale Eingang Spannung | 230 V |
