Broadcom MegaRAID 9540-8i 12Gb/s PCIe 4.0 x8 RAID 0/1/10 8 Internal Ports (Retail)
Broadcom MegaRAID 9540-8i RAID controller. PCIe 4.0 x8, 8 internal SAS/SATA 12Gb/s & NVMe ports. RAID 0,1,10,JBOD. SAS3808 ROC. Low profile MD2 form factor. MTBF 3M hours. Max 63 SAS/SATA +4 NVMe devices. Power 6W.
Please Note
The website is currently being actively developed, you are welcome to place the order and in 99% of the cases your order will be processed as usual, but in some cases there may be a delay or the price may change. We will notify you if there are any issues.
Discontinued
This item was discontinued and currently is not available for order on our website. The item may become available soon. Please contact us if you need more information regarding the upcoming arrivals.
| Expansion Cards - Product Type | Storage Controller and Adapter |
|---|---|
| Expansion Cards - Host Interface | PCIe x8 |
| Expansion Cards - Internal Connectivity | SAS Ports |
| Expansion Cards - Form Factor | Low Profile Half-Height |
| Expansion Cards - External Connectivity | Internal Only |
The Broadcom MegaRAID 9540-8i is a high-performance Tri-Mode storage adapter designed for data centers, cloud, and HPC environments. It delivers 12Gb/s SAS/SATA and PCIe Gen4 NVMe connectivity via PCIe 4.0 x8 host interface, providing twice the bandwidth of previous generations with 75% more IOPS.
Featuring the SAS3808 RAID-on-Chip controller and 1x SFF-8654 (SlimSAS) connector for 8 internal ports, it supports up to 63 SAS/SATA drives and 4 NVMe devices. RAID levels include 0, 1, 10, JBOD with features like fast rebuild and hot spare support. Low profile MD2 form factor (155.7x68.9mm) fits most servers. Operating temp 0-55°C, MTBF over 3,000,000 hours, typical power 6W.
- ✅ PCIe 4.0 x8 host interface
- ✅ 8 internal ports: SAS 12Gb/s, SATA 6Gb/s, PCIe 4.0 NVMe
- ✅ RAID 0, 1, 10, JBOD
- ✅ Low profile card, no cache
- ✅ Broad OS support: Windows, Linux, VMware, FreeBSD
| Host Interface | PCIe 4.0 x8 |
| Internal Ports | 8 |
| Internal Connectivity | 1 x SFF-8654 (SlimSAS) |
| RAID Levels | 0, 1, 10, JBOD |
| Data Transfer Rate | 12 Gbit/s SAS / 6 Gbit/s SATA / PCIe 4.0 NVMe |
| Controller Chip | SAS3808 |
| Max SAS/SATA Devices | 63 |
| Max NVMe Devices | 4 |
| Form Factor | Low Profile MD2 (155.7 x 68.9 mm) |
| MTBF | 3000000 h |
| Operating Temperature | 0 - 55 °C |
| Power Consumption | 6 W |
| OS Support | Windows, VMware, RHEL, SUSE, Ubuntu, Citrix, CentOS, Debian, Oracle, Fedora, FreeBSD |
| MPN | 05-50134-03 |
| Features | S.M.A.R.T. support, Universal Backplane Management ready |
