Chieftec VEGA PPG-850-S 850W 80+ Gold ATX PSU Non-Modular (Boxed)
850W 80 PLUS Gold certified ATX 12V 3.1 PSU. Non-modular design with 135mm FDB fan, LLC topology, PCIe GEN5 support, +12V 70.8A single rail. Compact 140mm length, black cables.
Please Note
The website is currently being actively developed, you are welcome to place the order and in 99% of the cases your order will be processed as usual, but in some cases there may be a delay or the price may change. We will notify you if there are any issues.
Discontinued
This item was discontinued and currently is not available for order on our website. The item may become available soon. Please contact us if you need more information regarding the upcoming arrivals.
| PSU (Power Supplies) - Wattage | 800 - 899 W |
|---|---|
| PSU (Power Supplies) - Efficiency Rating | 80 Plus Gold |
| PSU (Power Supplies) - Color | Black |
| PSU (Power Supplies) - Modularity | Non-modular |
| PSU (Power Supplies) - PCIe GPU Connectors | 4x 8/6 pins |
| PSU (Power Supplies) - Length | Up to 140 mm |
| PSU (Power Supplies) - EPS CPU Connectors | 1x 4+4pin EPS/ATX12V |
The Chieftec VEGA PPG-850-S is a high-efficiency 850W power supply unit compliant with Intel ATX 12V 3.1 standards and supporting PCIe GEN5 for modern gaming and high-performance systems. Featuring 80 PLUS Gold certification, it delivers up to 90% efficiency at typical loads, utilizing advanced LLC Half-Bridge converter with DC-to-DC technology for stable power delivery and reduced ripple.
Equipped with a quiet 135mm fluid dynamic bearing (FDB) fan and extra-long native black cables, this non-modular PSU is ideal for mainstream gamers building in larger cases. It includes essential protections like OPP, OVP, UVP, SCP, and OTP, ensuring reliable operation. The compact 140mm chassis fits most mid-tower cases while providing a powerful single +12V rail at 70.8A (850W).
- ✅ 80 PLUS Gold efficiency (up to 90% at 50% load)
- ✅ ATX 12V 3.1 & PCIe GEN5 compliant
- ✅ 135mm FDB silent fan for optimal cooling/noise
- ✅ Single +12V 70.8A rail (850W total)
- ✅ 1x 4+4-pin EPS12V, 4x 6+2-pin PCIe connectors
- ✅ Full suite of industrial protections
| Model | PPG-850-S |
| Power Output | 850W |
| Form Factor | ATX |
| ATX Version | ATX 12V 3.1 |
| Efficiency Certification | 80 PLUS Gold |
| Fan Size | 135mm FDB |
| Modularity | Non-Modular |
| Main Connector | 20+4 pin |
| CPU Connector | 1x 4+4-pin EPS/ATX12V |
| PCIe Connectors | 4x 6+2-pin (600W) |
| Single +12V Rail | 70.8A (850W) |
| +5V | 20A |
| +3.3V | 20A |
| Dimensions | 150x140x86 mm |
| Topology | LLC Half-Bridge + DC-DC |
| Protections | OPP/OVP/UVP/SCP/OTP |
| Input Voltage | 100-240V 50-60Hz |
| MTBF | 100,000 hours |
