Ubiquiti UPS-Tower
Ubiquiti UPS-Tower. Line-Interaktiv. 1 kVA. 600 W. Sine. 89 V. 145 V
Please Note
The website is currently being actively developed, you are welcome to place the order and in 99% of the cases your order will be processed as usual, but in some cases there may be a delay or the price may change. We will notify you if there are any issues.
Discontinued
This item was discontinued and currently is not available for order on our website. The item may become available soon. Please contact us if you need more information regarding the upcoming arrivals.
Ubiquiti UPS-Tower. USV-Topologie: Line-Interaktiv. Ausgangskapazität: 1 kVA. Ausgangsleistung: 600 W. AC-Steckertypen: C13-Koppler. C14-Koppler. Stecker: NEMA 5-15P. Anzahl der AC-Ausgänge: 10 AC-Ausgänge. Akku-/Batterietechnologie: Bleisäure. Batteriekapazität: 9 Ah. Akku-/Batteriespannung: 12 V. Formfaktor: Desktop. Produktfarbe: Weiß. Gehäusematerial: Acrylnitril-Butadien-Styrol (ABS). Polycarbonat (PC). Konformitätsbescheinigungen: CE. Eidgenössische Kommunikationskommission (FCC). Industry Canada (IC). National Defense...
| USV-Topologie | Line-Interaktiv |
| Ausgangskapazität | 1 kVA |
| Ausgangsleistung | 600 W |
| Wellenform | Sine |
| Eingangs-Betriebsspannung (min) | 89 V |
| Eingangs-Betriebsspannung (max) | 145 V |
| Eingangsfrequenz | 50/60 Hz |
| Output Frequenz | 50/60 Hz |
| Regulierung der Ausgangsspannung | 10% |
| Übertragungszeit (Line-Modus in Batterie-Modus) | 10 ms |
| Überlastbarkeit (5 Minuten) | 110% |
| Feature | Batteriestandsanzeige |
| Energieschutzeigenschaften | Überspannung. Überlastschutz. Kurzschluß |
| AC-Steckertypen | C13-Koppler. C14-Koppler |
| Stecker | NEMA 5-15P |
| Anzahl der AC-Ausgänge | 10 AC-Ausgänge |
| Anzahl Ethernet-LAN-Anschlüsse (RJ-45) | 3 |
| Akku-/Batterietechnologie | Bleisäure |
| Batteriekapazität | 108 Wh |
| Akku-/Batteriespannung | 12 V |
| Anzahl enthaltener Akkus/Batterien | 1 Stück(e) |
| Typische Backup-Zeit bei voller Belastung | 2 min |
| Typische Backup-Zeit bei halber Belastung | 7 min |
| Akkuladezeit | 8 h |
| Formfaktor | Desktop |
| Gehäusematerial | Acrylnitril-Butadien-Styrol (ABS). Polycarbonat (PC) |
| Produktfarbe | Weiß |
| Steuerung | Tasten |
| LED-Anzeigen | Status |
| Internationale Schutzart (IP-Code) | IP20 |
| Betriebstemperatur | 0 - 40 °C |
| Temperaturbereich bei Lagerung | -20 - 50 °C |
| Relative Luftfeuchtigkeit in Betrieb | 0 - 95% |
| Höhe bei Betrieb | 0 - 3000 m |
| Konformitätsbescheinigungen | CE. Eidgenössische Kommunikationskommission (FCC). Industry Canada (IC). National Defense Authorization Act (NDAA). UL |
| Mitgelieferte Kabel | Eingangskabel |
| Breite | 99 mm |
| Tiefe | 288 mm |
| Höhe | 280.5 mm |
| Gewicht | 8.17 kg |
| Nominale Ausgang Spannung | 120 V |
| Nominale Eingang Spannung | 120 V |
