Chieftec EON ZPU-500S 500W Non-Modular ATX PSU - 80 PLUS (Boxed)
500W non-modular ATX PSU with 80 PLUS Standard 230V EU efficiency, silent 120mm fan, Active PFC, and comprehensive protection (OPP, OVP, SCP, SIP, UVP). AC 200–240V input.
Please Note
The website is currently being actively developed, you are welcome to place the order and in 99% of the cases your order will be processed as usual, but in some cases there may be a delay or the price may change. We will notify you if there are any issues.
Discontinued
This item was discontinued and currently is not available for order on our website. The item may become available soon. Please contact us if you need more information regarding the upcoming arrivals.
| PSU (Power Supplies) - Wattage | 500 - 599 W |
|---|---|
| PSU (Power Supplies) - Efficiency Rating | 80 Plus White |
| PSU (Power Supplies) - Color | Black |
| PSU (Power Supplies) - Modularity | Non-modular |
| PSU (Power Supplies) - PCIe GPU Connectors | 2x 8/6 pins |
| PSU (Power Supplies) - Length | Up to 140 mm |
| PSU (Power Supplies) - EPS CPU Connectors | None |
The Chieftec EON ZPU-500S is a reliable 500W non-modular ATX power supply designed for standard PC builds and gaming systems. Featuring 80 PLUS Standard 230V EU certification, this PSU delivers up to 80% efficiency, reducing energy waste and operating costs. The unit employs Active Power Factor Correction (PFC 0.9) to optimize power delivery and minimize harmonic distortion.
Built with a silent 120mm fan and active cooling system, the ZPU-500S maintains stable performance under load while keeping operating temperatures low. The sleek black design integrates seamlessly into modern PC cases. All native cables are extra-long for flexible routing in larger chassis. The power supply complies with ATX 12V 2.3 specifications and includes comprehensive protection mechanisms against electrical faults.
Key specifications include 2x 20+4 PIN ATX motherboard connectors, 2x 6+2 pin PCIe GPU connectors, 4x SATA connectors, and 2x Molex connectors. AC input range is 200–240V at 50Hz with 3.5A input current. Dimensions are 140mm (D) x 150mm (W) x 86mm (H).
- 80 PLUS Standard 230V EU efficiency certification
- Active Power Factor Correction (PFC 0.9)
- Silent 120mm cooling fan with automatic speed control
- Non-modular design with extra-long native cables
- Multiple protection features: OPP, OVP, SCP, SIP, UVP
- ATX 12V 2.3 compliant
- Elegant black finish for modern PC aesthetics
| Model | ZPU-500S |
| Series | EON |
| Power Output | 500 W |
| Form Factor | ATX |
| ATX Standard | ATX 12V 2.3 |
| Efficiency Rating | 80 PLUS Standard 230V EU |
| Modularity | Non-modular |
| Cooling | Active cooling with 120mm silent fan |
| Fan Diameter | 120 mm |
| Power Factor Correction | Active PFC (0.9) |
| AC Input Voltage | 200 - 240 V |
| AC Input Frequency | 50 Hz |
| Input Current | 3.5 A |
| Motherboard Connectors (20+4 PIN ATX) | 2x |
| PCIe GPU Connectors (6+2 pin) | 2x |
| SATA Power Connectors | 4x |
| Molex/Peripheral Connectors (4-pin) | 2x |
| EPS CPU Connectors (4+4 pin) | 0x |
| 12VHPWR Connectors | 0x |
| +12V1 Output Current | 37 A |
| +5V Output Current | 20 A |
| +3.3V Output Current | 20 A |
| +5V & +3.3V Combined Power | 100 W |
| +5VSB Output | 2.5 A / 12.5 W |
| -12V Output | 0.4 A / 4.8 W |
| Motherboard Cable Length | 65 cm |
| SATA Cable Lengths | 450 mm, 600 mm, 750 mm |
| Molex Cable Lengths | 450 mm, 600 mm, 750 mm |
| Dimensions (D x W x H) | 140 mm x 150 mm x 86 mm |
| Weight (without packaging) | 1.34 kg |
| Weight (with packaging) | 1.62 kg |
| Color | Elegant Black |
| Protection Features | AFC (Automatic Fan Speed Control), OPP (Over Power Protection), OVP (Over Voltage Protection), SCP (Short Circuit Protection), SIP (Surge & Inrush Protection), UVP (Under Voltage Protection) |
| Warranty | 24 Months |
| Country of Origin | Germany |
