DELL Switch S4148F 48SFP+ 4QSFP QSF+ 48xSPF+ 4xQSFP28 2xQSFP+ red.NT L3
DELL S-Series S4148F-ON. Managed. L2/L3. Rack-Einbau. 1U
Please Note
The website is currently being actively developed, you are welcome to place the order and in 99% of the cases your order will be processed as usual, but in some cases there may be a delay or the price may change. We will notify you if there are any issues.
Discontinued
This item was discontinued and currently is not available for order on our website. The item may become available soon. Please contact us if you need more information regarding the upcoming arrivals.
DELL S-Series S4148F-ON. Switch-Typ: Managed. Switch-Ebene: L2/L3. Anzahl USB 2.0 Anschlüsse: 1. Konsolen-Port: RJ-45/Micro-USB. MAC-Adressentabelle: 272000 Eintragungen. Routing-/Switching-Kapazität: 1760 Gbit/s. Netzstandard: IEEE 802.3. Netzstecker: AC-Eingangsbuchse. Rack-Einbau. Formfaktor: 1U
| Switch-Typ | Managed |
| Switch-Ebene | L2/L3 |
| Feature | Netzteil enthalten |
| MIB Unterstützung | IP MIB. IP Forward MIB. Host Resources MIB. IF MIB. LLDP MIB. Entity MIB. LAG MIB. Dell-Vendor MIB. TCP MIB. UDP MIB. SNMPv2 MIB |
| Anzahl Gigabit Ethernet (Kupfer) Anschlüsse | 1 |
| Menge Modul-Steckplätze SFP+ | 48 |
| Anzahl QSFP + Modulsteckplätze | 2 |
| Konsolen-Port | RJ-45/Micro-USB |
| Anzahl USB 2.0 Anschlüsse | 1 |
| Netzstecker | AC-Eingangsbuchse |
| Netzstandard | IEEE 802.3 |
| Virtuelle LAN-Funktionen | Tagged VLAN |
| Routing-/Switching-Kapazität | 1760 Gbit/s |
| Durchgang | 1320 Mpps |
| MAC-Adressentabelle | 272000 Eintragungen |
| Jumbo-Frames | 9416 |
| Datenpaket-Pufferspeicher | 12 MB |
| Management-Protokolle | CLI. SNMP. REST. API’s |
| Formfaktor | 1U |
| Produktfarbe | Schwarz |
| Belüftungssystem | Luftstrom von vorne nach hinten |
| Speicherkapazität | 4000 MB |
| Anzahl von Stromversorgungseinheiten | 2 |
| AC Eingangsspannung | 100 - 240 V |
| AC Eingangsfrequenz | 50 - 60 Hz |
| Stromverbrauch (Standardbetrieb) | 200 W |
| Stromverbrauch (max.) | 370 W |
| Betriebstemperatur | 5 - 45 °C |
| Temperaturbereich bei Lagerung | -40 - 65 °C |
| Relative Luftfeuchtigkeit in Betrieb | 5 - 85% |
| Luftfeuchtigkeit bei Lagerung | 5 - 95% |
| Breite | 431 mm |
| Tiefe | 457 mm |
| Höhe | 44 mm |
| Gewicht | 9.46 kg |
| Warentarifnummer (HS) | 85176990 |
