Seasonic Focus GX-750 V4 White - 750W ATX 3.1 80+ Gold Fully-Modular PSU - FOCUS-GX-750-V4-WHITE (Boxed)
Seasonic Focus GX-750 V4 White: 750W ATX 3.1 PSU, 80+ Gold, fully modular, 135mm FDB fan, hybrid silent mode. Supports PCIe 5.1 (12V-2x6 + 2x6+2), 1x EPS, compact 140mm depth, 10yr warranty.
Please Note
The website is currently being actively developed, you are welcome to place the order and in 99% of the cases your order will be processed as usual, but in some cases there may be a delay or the price may change. We will notify you if there are any issues.
Discontinued
This item was discontinued and currently is not available for order on our website. The item may become available soon. Please contact us if you need more information regarding the upcoming arrivals.
| PSU (Power Supplies) - Wattage | 700 - 799 W |
|---|---|
| PSU (Power Supplies) - Efficiency Rating | 80 Plus Gold |
| PSU (Power Supplies) - Color | White |
| PSU (Power Supplies) - Modularity | Fully modular |
| PSU (Power Supplies) - PCIe GPU Connectors | 1x 12V-2x6 2x 8/6 pins |
| PSU (Power Supplies) - Length | 141-160 mm |
| PSU (Power Supplies) - EPS CPU Connectors | 1x 4+4pin EPS/ATX12V |
The Seasonic Focus GX-750 V4 White is a premium 750W power supply updated for ATX 3.1 and PCIe 5.1 standards, ideal for modern gaming PCs and high-performance builds. Featuring 80+ Gold efficiency, fully modular cabling for clean builds, and a compact 140mm depth that fits most ATX cases. The white finish adds aesthetic appeal to visible setups.
Equipped with a 135mm Fluid Dynamic Bearing (FDB) fan and Seasonic's Hybrid Silent Fan Control (S3FC), it operates fanless up to 30% load for whisper-quiet performance, switching to silent or cooling modes as needed. Delivers 744W on the single +12V rail with tight regulation, supporting power excursions for next-gen GPUs.
- ✅ ATX 3.1 & PCIe 5.1 compliant with 1x 12V-2x6 (16-pin) + 2x 6+2 PCIe connectors
- ✅ 1x 4+4 pin EPS for CPU power
- ✅ Protection: OPP/OVP/UVP/OTP/SCP/OCP
- ✅ 10-year warranty, 100,000h MTBF
- ✅ Operating temp: 0-50°C
| Total power | 750 W |
| AC input voltage | 100 - 240 V |
| AC input frequency | 50/60 Hz |
| Input current | 10 - 5 A |
| Combined power (+3.3V) | 100 W |
| Combined power (+12V) | 744 W |
| Combined power (+5V) | 100 W |
| Combined power (-12V) | 3.6 W |
| Combined power (+5Vsb) | 15 W |
| Max output current (+3.3V) | 20 A |
| Max output current (+12V) | 62 A |
| Max output current (+5V) | 20 A |
| Max output current (-12V) | 0.3 A |
| Max output current (+5Vsb) | 3 A |
| Power protection features | Over current, Over power, Over voltage, Overheating, Short circuit, Under voltage |
| Motherboard power connector | 24-pin ATX |
| Cabling type | Fully-Modular |
| 80 PLUS certification | 80 PLUS Gold |
| Purpose | PC |
| Power supply unit (PSU) form factor | ATX |
| ATX version | 3.1 |
| Bearing technology | FDB |
| Mean time between failures (MTBF) | 100000 h |
| Product colour | White |
| Cooling type | Active |
| Fan diameter | 13.5 cm |
| Number of fans | 1 fan(s) |
| Operating temperature (T-T) | 0 - 50 °C |
| Width | 150 mm |
| Depth | 140 mm |
| Height | 86 mm |
| PCI Express power connectors (6+2 pin) | 2 |
| PCI Express power connectors (12+4 pin) | 1 (12V-2x6) |
| CPU power connector (4+4 pin) | Yes |
| Silent mode | Yes |
