MSI GeForce GT 1030 2GHD4 LP OC 2GB GDDR4 Passive Low Profile (Boxed)
MSI GeForce GT 1030 2GHD4 LP OC: Passive low-profile GPU with NVIDIA GP108, 384 CUDA cores, 2GB GDDR4, 1189 MHz base/1430 MHz boost, 64-bit 2100 MHz memory. HDMI 2.0b + DP 1.4a, 30W TDP, ideal for HTPC/office.
Please Note
The website is currently being actively developed, you are welcome to place the order and in 99% of the cases your order will be processed as usual, but in some cases there may be a delay or the price may change. We will notify you if there are any issues.
Discontinued
This item was discontinued and currently is not available for order on our website. The item may become available soon. Please contact us if you need more information regarding the upcoming arrivals.
| GPU (Graphics Cards) - Series | NVIDIA GeForce GT |
|---|---|
| GPU (Graphics Cards) - PCIe Interface | PCIe 3.0 x16 |
| GPU (Graphics Cards) - Cooler Type | Passive |
| GPU (Graphics Cards) - Color | Black |
| GPU (Graphics Cards) - Backplate | No |
| GPU (Graphics Cards) - VRAM Capacity | 2 GB |
| GPU (Graphics Cards) - VRAM Type | GDDR4 |
| GPU (Graphics Cards) - Outputs | DisplayPort 1.4 HDMI 2.0 |
| GPU (Graphics Cards) - Power Connector | None |
| GPU (Graphics Cards) - Card Length | Low Profile (Under 170 mm) |
The MSI GeForce GT 1030 2GHD4 LP OC is a compact, passively cooled graphics card designed for small form factor systems and HTPCs. Featuring NVIDIA's Pascal-based GP108 GPU with 384 CUDA cores, it delivers reliable performance for everyday computing, light gaming, video playback, and multi-monitor setups. The low-profile bracket and half-height design ensure compatibility with slim cases, while the large heatsink provides silent operation without fans.
Key specs include a base clock of 1189 MHz boosting to 1430 MHz, 2GB GDDR4 memory on a 64-bit bus at 2100 MHz, supporting DirectX 12 and OpenGL 4.5. It connects via PCIe 3.0 x16 (x4 electrically) and offers one HDMI 2.0b and one DisplayPort 1.4a for up to 2 displays. No additional power connector is required, drawing just 20-30W from the slot, with a recommended 300W PSU.
- Ideal for: Office work, 1080p video, eSports at low settings, multi-monitor productivity
- Cooling: Passive heatsink (zero noise)
- Dimensions: 150 x 69 x 38 mm, 304g (card only)
- Form Factor: Low-profile, single-slot
| CUDA Cores | 384 |
| Graphics Processor Family | NVIDIA |
| GPU | GeForce GT 1030 |
| Base Clock | 1189 MHz |
| Boost Clock | 1430 MHz |
| VRAM Capacity | 2 GB |
| VRAM Type | GDDR4 |
| Memory Bus | 64 Bit |
| Memory Clock | 2100 MHz |
| Interface | PCI Express x16 3.0 |
| HDMI Ports | 1 |
| HDMI Version | 2.0b |
| DisplayPort Ports | 1 |
| DisplayPort Version | 1.4a |
| DirectX | 12.0 |
| OpenGL | 4.5 |
| Cooling | Passive |
| Form Factor | Half-Height/Half-Length (HH/HL) |
| Bracket Height | Low-Profile (LP) |
| Slots | 1 |
| Color | Black |
| Min PSU | 300 W |
| Power Consumption | 20 W |
| Weight | 304 g |
| Length | 150 mm |
| Depth | 38 mm |
| Height | 69 mm |
| Package Weight | 544 g |
