SPIRE SP08025S1ME4 80mm Case Fan 32 CFM 12VDC (Retail Blister)
SPIRE 80mm case fan with 32 CFM airflow, 12VDC operation, 4-pin Molex connector, and 30,000-hour lifespan. Sleeve bearing design operates at 2500 RPM with 28 dB noise level.
Please Note
The website is currently being actively developed, you are welcome to place the order and in 99% of the cases your order will be processed as usual, but in some cases there may be a delay or the price may change. We will notify you if there are any issues.
Discontinued
This item was discontinued and currently is not available for order on our website. The item may become available soon. Please contact us if you need more information regarding the upcoming arrivals.
| Cooling (CPU & Case) - Device Type | Case Fan |
|---|---|
| Cooling (CPU & Case) - Fan Size | 80 mm |
| Cooling (CPU & Case) - Lightning | None |
| Cooling (CPU & Case) - Connector | Molex |
| Cooling (CPU & Case) - Color | Black |
| Cooling (CPU & Case) - Special Features | Low Noise |
The SPIRE SP08025S1ME4 is a compact 80mm case cooling fan designed for standard PC case installations. Featuring a sleeve bearing mechanism and 12VDC operation, this fan delivers 32 CFM of airflow at 2500 RPM while maintaining a quiet 28 dB noise profile, making it suitable for silent or low-noise system builds.
This fan connects via a standard 4-pin Molex 8981 connector and operates reliably across a wide temperature range from -10°C to 70°C. With a rated power consumption of just 1.92W and 0.18A current draw, it is energy-efficient and compatible with most standard PC power supplies. The fan is rated for 30,000 hours of continuous operation, providing excellent durability for long-term use.
The product comes in retail blister packaging and includes one mounting screw for easy installation. Its compact 12x12x2 cm bracket dimensions allow flexible mounting in various case configurations.
- 80mm fan size with 32 CFM airflow output
- 12VDC operation with 4-pin Molex connector
- Sleeve bearing design rated for 30,000 hours
- Quiet 28 dB noise level at 2500 RPM
- Low power consumption: 1.92W at 0.18A
- Operating temperature range: -10°C to 70°C
- Includes mounting screw; retail blister packaging
| Fan Size | 80 x 80 x 30 mm |
| Fan Type | 12VDC |
| Airflow | 32 CFM |
| Rated Speed | 2500 RPM (±10%) |
| Noise Level | 28 dB(A) |
| Bearing Type | Sleeve Bearing |
| Connector | 4-pin Molex 8981 |
| Rated Power | 1.92 W |
| Rated Current | 0.18 A |
| Voltage Input | 12 V DC |
| Static Pressure | 2.54 mmH2O |
| Life Expectancy | 30,000 hours |
| Operating Temperature | -10°C to 70°C |
| Storage Temperature | -40°C to 70°C |
| PWM Support | No |
| LED | None |
| Bracket Dimensions | 12.00 x 12.00 x 2.00 cm |
| Unit Weight | 80 g |
| Accessories Included | 1x Mounting Screw |
| Packaging Type | Retail Blister |
