Titan TFD-5010M12Z 50x50x10mm 3-Pin Case Fan 4500RPM (Boxed)
Titan 33349Z (TFD-5010M12Z) 50x50x10mm case fan with 3-pin motherboard + Molex connectors. 4500 RPM speed delivers 14.67 m³/h (8.65 CFM) airflow at
Please Note
The website is currently being actively developed, you are welcome to place the order and in 99% of the cases your order will be processed as usual, but in some cases there may be a delay or the price may change. We will notify you if there are any issues.
Discontinued
This item was discontinued and currently is not available for order on our website. The item may become available soon. Please contact us if you need more information regarding the upcoming arrivals.
| Cooling (CPU & Case) - Device Type | Case Fan |
|---|---|
| Cooling (CPU & Case) - Fan Size | 60 mm |
| Cooling (CPU & Case) - Lightning | None |
| Cooling (CPU & Case) - Connector | 3-Pin Molex |
| Cooling (CPU & Case) - Color | Black |
| Cooling (CPU & Case) - Special Features | Low Noise Low Profile |
The Titan 33349Z, model TFD-5010M12Z, is a compact 50x50x10mm DC cooling fan designed for efficient airflow in small form factor PCs, servers, and embedded systems. It operates at 12V with both 3-pin motherboard connector for speed control and Molex power connector for versatility. Featuring a z-axis bearing, it ensures smooth, reliable operation with low friction and extended lifespan.
With a high speed of 4500 RPM, this fan provides maximum airflow of 14.67 m³/h (8.65 CFM) while maintaining noise levels under 23 dBA, making it suitable for noise-sensitive environments. The low-profile 10mm thickness allows installation in tight spaces where larger fans cannot fit.
- Dimensions: 50 x 50 x 10 mm
- Speed: 4500 RPM
- Airflow: 14.67 m³/h
- Noise: <23 dBA
- Connectors: 3-pin + Molex
- Bearing: Z-axis
| Model | TFD-5010M12Z / 33349Z |
| Fan Dimensions | 50 x 50 x 10 mm |
| Rated Voltage | 12 VDC |
| Speed | 4500 RPM |
| Max Airflow | 14.67 m³/h (8.65 CFM) |
| Noise Level | <23 dBA |
| Bearing Type | Z-Axis Bearing |
| Connectors | 3-pin (motherboard) + Molex |
| Power Connector | 12V Molex |
