GIGABYTE GeForce RTX 5060 Ti Aero OC - White, 8GB GDDR7, 2647 MHz, PCIe 5.0
GIGABYTE GeForce RTX 5060 Ti Aero OC — 8GB GDDR7, 4608 CUDA cores, PCIe 5.0 x8, WinForce 3X triple-fan cooling, 1x HDMI 2.1b, 3x DisplayPort 2.1, 281 mm length.
Please Note
The website is currently being actively developed, you are welcome to place the order and in 99% of the cases your order will be processed as usual, but in some cases there may be a delay or the price may change. We will notify you if there are any issues.
| GPU (Graphics Cards) - VRAM Capacity | 8 GB |
|---|---|
| GPU (Graphics Cards) - Outputs | DisplayPort |
| GPU (Graphics Cards) - Power Connector | 1x8-pin |
| GPU (Graphics Cards) - Card Length | 281-320 mm |
| GPU (Graphics Cards) - Slot Thickness | 2-slot |
| GPU (Graphics Cards) - Cooler Type | Open-air (axial) |
GIGABYTE GeForce RTX 5060 Ti AERO OC 8G Graphics Card - 8GB GDDR7. 128bit. PCI-E 5.0. 2647MHz Core Clock. 3 x DisplayPort. 1 x HDMI. GV-N506TAERO OC-8GD. Graphics processor family: NVIDIA. Graphics processor: GeForce RTX 5060 Ti. Processor frequency: 2647 MHz. Discrete graphics card memory: 8 GB. Graphics card memory type: GDDR7. Memory bus: 128 bit. Memory clock speed: 28000 MHz. Maximum resolution: 7680 x 4320 pixels. DirectX version: 12.0. OpenGL version: 4.6. Interface type: PCI Express x8 5.0. Cooling type: Active. Number of fans: 3 fan(s)
| Feature | Overclocked (OC) edition |
| CUDA cores | 4608 |
| Graphics processor family | NVIDIA |
| Graphics processor | GeForce RTX 5060 Ti |
| Processor frequency | 2647 MHz |
| Maximum resolution | 7680 x 4320 pixels |
| Parallel processing technology support | Not supported |
| Maximum displays per videocard | 4 |
| Discrete graphics card memory | 8 GB |
| Graphics card memory type | GDDR7 |
| Memory bus | 128 bit |
| Memory clock speed | 28000 MHz |
| Data transfer rate | 28 Gbit/s |
| Interface type | PCI Express x8 5.0 |
| HDMI ports quantity | 1 |
| HDMI version | 2.1b |
| DisplayPorts quantity | 3 |
| DisplayPort version | 2.1b |
| DirectX version | 12.0 |
| OpenGL version | 4.6 |
| Warranty period | 3 year(s) |
| Cooling type | Active |
| Cooling technology | GIGABYTE WINDFORCE 3X |
| Number of fans | 3 fan(s) |
| Form factor | Full-Height/Full-Length (FH/FL) |
| Number of slots | 2 |
| Product colour | White |
| Minimum system power supply | 650 W |
| Supplementary power connectors | 1x 8-pin |
| Thermal Design Power (TDP) | 135 W |
| Weight | 820 g |
| Length | 281 mm |
| Depth | 40 mm |
| Height | 117 mm |
| Package width | 182.5 mm |
| Package depth | 354 mm |
| Package height | 75 mm |
| Package weight | 1.29 kg |
| Package type | Box |
| Products per shipping (inner) case | 1 pc(s) |
