LogiLink PC0090 USB 3.2 Gen 1 PCIe Card - 2x USB-A + 1x USB-C PD (Boxed)
LogiLink PC0090 PCIe expansion card with 2x USB 3.2 Gen 1 Type-A and 1x USB-C PD 3.0 port. Delivers 5 Gbps data transfer and 30W power delivery. Includes low profile bracket.
Please Note
The website is currently being actively developed, you are welcome to place the order and in 99% of the cases your order will be processed as usual, but in some cases there may be a delay or the price may change. We will notify you if there are any issues.
Discontinued
This item was discontinued and currently is not available for order on our website. The item may become available soon. Please contact us if you need more information regarding the upcoming arrivals.
| Expansion Cards - Product Type | IO Port Expansion |
|---|---|
| Expansion Cards - Host Interface | PCIe x1 |
| Expansion Cards - Internal Connectivity | External Only |
| Expansion Cards - Form Factor | Low Profile Half-Height |
| Expansion Cards - External Connectivity | USB Type-A USB Type-C and Thunderbolt |
The LogiLink PC0090 is a PCI Express 2.0 expansion card that adds high-speed USB connectivity to desktop computers. It features two USB 3.2 Gen 1 Type-A ports and one USB 3.2 Gen 1 Type-C port with Power Delivery 3.0 support, enabling up to 5 Gbps data transfer rates and 30W maximum power output for charging compatible devices. The card is powered by both the PCIe bus and an optional ATX 6-pin connector for stable operation.
Designed for easy installation, the PC0090 includes a low-profile bracket for compact cases and supports hot-plug and plug-and-play functionality. It is compatible with Windows 7, 8.x, 10, 11, Windows Server 2008 R2 through 2022, and Linux Kernel 2.6 or later. The card operates reliably across a wide temperature range (0-85°C) and includes built-in protection against over-voltage, over-current, and over-temperature conditions.
Key Features:
- 2x USB 3.2 Gen 1 Type-A ports with 5 Gbps speed
- 1x USB 3.2 Gen 1 Type-C port with USB Power Delivery 3.0 (30W max)
- PCI Express 2.0 1-Lane interface compliance
- Low-profile bracket included for space-constrained builds
- ATX 6-pin power connector for enhanced stability
- Hot-plug and Plug & Play support
- Comprehensive OS compatibility (Windows and Linux)
- Built-in protection circuits (over-voltage, over-current, over-temperature)
| Type | PCI Express Expansion Card |
| Host Interface | PCI Express 2.0 1-Lane (x1) |
| External Ports | 2x USB 3.2 Gen 1 Type-A, 1x USB 3.2 Gen 1 Type-C |
| Data Transfer Rate | 5 Gbps |
| USB Power Delivery | USB-C PD 3.0, 30W max (20V/1.5A) |
| Power Supply | PCIe bus power + ATX 6-pin connector |
| Chipset | VL805 |
| Form Factor | Low Profile |
| Bracket | Low Profile Bracket included |
| Dimensions (Device) | 12 x 10.3 x 2.15 cm |
| Weight (Device) | 60 g |
| Operating Temperature | 0–85°C |
| Operating Humidity | 0–95% RH (no condensation) |
| Protection Features | Over-voltage, over-current, over-temperature protection |
| Hot Plug Support | Yes |
| Plug & Play | Yes |
| Windows Compatibility | Windows 7, 8.x, 10, 11, Windows Server 2008 R2, 2012 R2, 2016, 2019, 2022 (32/64-bit) |
| Linux Compatibility | Linux Kernel 2.6 or later |
| Package Contents | 1x USB 3.2 Gen 1 PCIe Card, 1x Low Profile Bracket, 1x User Manual |
| Packaging Dimensions | 150 x 135 x 30 mm |
| Packaging Weight | 0.11 kg |
