Inline 76617L SATA 6Gb/s Controller 4x PCIe 2.0 x1 (Boxed)
Inline 76617L PCIe 2.0 x1 SATA controller adds 4x 6Gb/s ports. Supports AHCI, NCQ, hot-swap. Backward compatible with SATA 3/1.5Gb/s. LED activity indicator. For Win/Linux/Mac. ASMedia ASM1064.
Please Note
The website is currently being actively developed, you are welcome to place the order and in 99% of the cases your order will be processed as usual, but in some cases there may be a delay or the price may change. We will notify you if there are any issues.
Discontinued
This item was discontinued and currently is not available for order on our website. The item may become available soon. Please contact us if you need more information regarding the upcoming arrivals.
| Expansion Cards - Product Type | Storage Controller and Adapter |
|---|---|
| Expansion Cards - Host Interface | PCIe x1 |
| Expansion Cards - Internal Connectivity | SATA Ports |
| Expansion Cards - Form Factor | Low Profile Half-Height Standard Profile Full-Height |
| Expansion Cards - External Connectivity | Internal Only |
The Inline 76617L is a high-performance PCI Express SATA controller card that expands your system with four SATA 6Gb/s ports using a native PCIe 2.0 x1 interface. Based on the reliable ASMedia ASM1064 chipset, it delivers speeds up to 6 Gb/s and is fully compliant with Serial ATA Revision 3.2, while remaining backward compatible with 3.0 Gb/s and 1.5 Gb/s SATA devices.
Key features include AHCI mode, Native Command Queuing (NCQ), FIS-based port multiplier support, and hot-plug/hot-swap functionality. The unique HDD activity LED blinks during read/write operations on connected drives. It fits in any PCIe x1 slot (and larger x2/x4/x8/x16) and includes a low-profile bracket for compact builds. Compatible with Windows 10/8/7 (32/64-bit), Linux, and Mac OS.
- 4x Internal SATA 6Gb/s ports
- PCIe 2.0 x1 host interface (5 Gbps bandwidth)
- Supports bootable drives and hot-swap
- HDD activity LED indicator
- Package: Card, low-profile bracket, manual
| Chipset | ASMedia ASM1064 |
| Host Interface | PCIe 2.0 x1 (backward compatible x2/x4/x8/x16) |
| SATA Ports | 4 x SATA 6Gb/s (internal) |
| Max Transfer Rate | 6 Gb/s per port |
| SATA Specification | Serial ATA Revision 3.2 |
| Backward Compatibility | SATA 3.0 Gb/s, 1.5 Gb/s |
| Modes Supported | AHCI, Native Command Queuing (NCQ) |
| Hot-Swap | Yes |
| Port Multiplier | FIS switch / command switch |
| Activity LED | Yes (HDD read/write indicator) |
| OS Support | Windows 10/8/7 (32/64-bit), Linux, Mac OS |
| Package Contents | PCIe card, low-profile bracket, user manual |
| Form Factor | Low-profile / full-height bracket |
