Seasonic FOCUS SGX-750 750W SFX PSU (ATX 2.4 Compatible) - 80 PLUS Gold, Fully-Modular, SSR-750SGX (Boxed)
Compact 750W SFX PSU (125×100×63.5mm) - 80 PLUS Gold certified, fully modular with SFX-to-ATX bracket. Hybrid fan control ensures quiet operation; 62A on +12V rail powers high-end SFF builds. 10-year warranty.
Please Note
The website is currently being actively developed, you are welcome to place the order and in 99% of the cases your order will be processed as usual, but in some cases there may be a delay or the price may change. We will notify you if there are any issues.
Discontinued
This item was discontinued and currently is not available for order on our website. The item may become available soon. Please contact us if you need more information regarding the upcoming arrivals.
| PSU (Power Supplies) - Wattage | 700 - 799 W |
|---|---|
| PSU (Power Supplies) - Efficiency Rating | 80 Plus Gold |
| PSU (Power Supplies) - Color | Black |
| PSU (Power Supplies) - Modularity | Fully modular |
| PSU (Power Supplies) - PCIe GPU Connectors | 3x 8/6 pins |
| PSU (Power Supplies) - Length | Up to 140 mm |
| PSU (Power Supplies) - EPS CPU Connectors | 2x 4+4pin EPS/ATX12V |
The Seasonic FOCUS SGX-750 is a premium compact power supply designed for small form factor (SFF) systems. Measuring just 125 mm (L) x 100 mm (W) x 63.5 mm (H), this standard SFX unit fits perfectly in mini-ITX chassis while including an SFX-to-ATX adapter bracket for standard ATX cases, optimizing airflow space.
Certified 80 PLUS Gold with up to 92.5% efficiency at typical loads, it delivers 744W combined on the +12V rail (62A max). Fully modular cabling reduces clutter, and the hybrid S3FC fan control with a 92mm Hong Hua FDB fan stays silent below 30% load. Protection features include OPP, OVP, UVP, SCP, OCP, OTP. Backed by a 10-year warranty.
- 3x PCIe 6+2-pin (8/6-pin) GPU connectors for modern graphics cards
- 1x 4+4-pin EPS CPU connector
- 6x SATA, 3x Molex peripheral connectors
- 20+4-pin ATX motherboard connector
- Supports ATX 2.4 standard, full power up to 50°C
| Total power | 750 W |
| AC input voltage | 100 - 240 V |
| AC input frequency | 50 - 60 Hz |
| Maximum input current (@110V) | 10 A |
| Maximum input current (@220V) | 5 A |
| Combined power (+3.3V) | 100 W |
| Combined power (+12V) | 744 W |
| Combined power (+5V) | 100 W |
| Combined power (-12V) | 3.6 W |
| Combined power (+5Vsb) | 15 W |
| Max output current (+3.3V) | 20 A |
| Max output current (+12V) | 62 A |
| Max output current (+5V) | 20 A |
| Max output current (-12V) | 0.3 A |
| Max output current (+5Vsb) | 3 A |
| Motherboard power connector | 20+4 pin ATX |
| CPU power connector (4+4 pin) | 1x Yes |
| PCIe power connectors (6+2 pin) | 3x |
| Number of SATA power connectors | 6 |
| Peripheral (Molex) power connectors (4-pin) | 3 |
| Cabling type | Fully-Modular |
| 80 PLUS certification | 80 PLUS Gold |
| Power supply unit (PSU) form factor | SFX |
| Fan diameter | 9.2 cm |
| Number of fans | 1 fan(s) |
| Warranty | 10 years |
| Mean time between failures (MTBF) | 100000 h |
| Product colour | Black |
| Cooling type | Hybrid fan control (S3FC) |
| Protection features | OPP, OVP, UVP, SCP, OCP, OTP |
| Width | 125 mm |
| Depth | 100 mm |
| Height | 63.5 mm |
| Operating temperature (T-T) | 0 - 50 °C |
