Intel Wi-Fi 6E AX211 M.2 2230 Network Adapter - AX211.NGWG.NV - Wi-Fi 6E, 2x2 (2400 Mbps), Bluetooth 5.2
Compact M.2 2230 Wi‑Fi 6E AX211 adapter with 2x2 MU‑MIMO, up to 2400 Mbps and Bluetooth 5.2. Compatible with Windows 10 x64, Linux and ChromeOS.
Please Note
The website is currently being actively developed, you are welcome to place the order and in 99% of the cases your order will be processed as usual, but in some cases there may be a delay or the price may change. We will notify you if there are any issues.
| PCIe Network Cards - OS Compatibility | Multi-OS |
|---|
Orthogonal Frequency-Division Multiple Access (OFDMA)
Orthogonal Frequency-Division Multiple Access (OFDMA) is a multi-user version of the popular orthogonal frequency-division multiplexing (OFDM) digital modulation scheme. This allows simultaneous low-data-rate transmission from several users.
| Connectivity technology | Wireless |
| Host interface | M.2 |
| Interface | WLAN |
| Maximum data transfer rate | 2400 Mbit/s |
| Wi-Fi | Yes |
| Top Wi-Fi standard | Wi-Fi 6E (802.11ax) |
| Wi-Fi standards | Wi-Fi 6E (802.11ax) |
| MU-MIMO | Yes |
| Bluetooth | Yes |
| Bluetooth version | 5.2 |
| Component for | PC/Laptop |
| Internal | Yes |
| Antenna type | 2x2 |
| Package size | 22 x 30 x 2.4 mm |
| Compatible operating systems | Windows 10, 64-bit*|Linux* |
| Windows operating systems supported | Windows 10 x64 |
| Linux operating systems supported | Yes |
| Other operating systems supported | ChromeOS |
| Operating temperature (T-T) | 0 - 80 °C |
| Width | 22 mm |
| Depth | 2.4 mm |
| Height | 30 mm |
| Weight | 2.83 g |
| Harmonized System (HS) code | 85176990 |
| Minimum operating temperature | 0 °C |
| Maximum operating temperature | 80 °C |
| Supported Under vPro | Yes |
| Launch date | Q3'21 |
| Status | Launched |
| Processor family | Intel Wi-Fi 6E Products |
| Export Control Classification Number (ECCN) | 5A991 |
| Commodity Classification Automated Tracking System (CCATS) | NA |
| Compliance | FIPS, FISMA |
| Product series | Intel® Wireless Products |
