Gigabyte GeForce RTX 5070 EAGLE OC SFF - Black, 12GB GDDR7, OC 2587MHz, PCIe 5.0, GV-N5070EAGLE-OC-12GD (Boxed)
GeForce RTX 5070 EAGLE OC SFF with 12GB GDDR7, 6144 CUDA cores, 2587MHz boost clock, WINDFORCE 3X cooling with Hawk fans. Features Blackwell architecture, DLSS 4, NVIDIA SFF-ready design, RGB Fusion. 3xDP 2.1b, 1xHDMI 2.1b, 16-pin power, 750W PSU recommended.
Please Note
The website is currently being actively developed, you are welcome to place the order and in 99% of the cases your order will be processed as usual, but in some cases there may be a delay or the price may change. We will notify you if there are any issues.
Discontinued
This item was discontinued and currently is not available for order on our website. The item may become available soon. Please contact us if you need more information regarding the upcoming arrivals.
| GPU (Graphics Cards) - Series | NVIDIA GeForce RTX |
|---|---|
| GPU (Graphics Cards) - PCIe Interface | PCIe 5.0 x16 |
| GPU (Graphics Cards) - Cooler Type | Triple Fan |
| GPU (Graphics Cards) - Color | Black |
| GPU (Graphics Cards) - Backplate | Yes |
| GPU (Graphics Cards) - VRAM Capacity | 12 GB |
| GPU (Graphics Cards) - VRAM Type | GDDR7 |
| GPU (Graphics Cards) - Outputs | DisplayPort 2.1 HDMI 2.1 |
| GPU (Graphics Cards) - Power Connector | 12VHPWR 16-pin |
| GPU (Graphics Cards) - Card Length | Large (281-300 mm) |
Experience next-generation gaming with the Gigabyte GeForce RTX 5070 EAGLE OC SFF 12G, powered by NVIDIA's Blackwell architecture and DLSS 4 for AI-enhanced performance. This overclocked edition boosts to 2587MHz (reference 2512MHz) with 6144 CUDA cores, 12GB GDDR7 memory at 28Gbps on a 192-bit bus, delivering superior frame rates and ray-traced visuals.
The WINDFORCE 3X cooling system features Hawk fans, server-grade thermal gel, and alternate spinning for optimal airflow and low noise. NVIDIA SFF-ready design ensures compatibility with small form factor builds, while RGB lighting and reinforced structure add style and durability. Supports full ray tracing, NVIDIA Reflex 2, and up to 4 displays at 7680x4320 resolution.
- PCIe 5.0 x16 interface, 250W TGP, 1x 16-pin power connector
- Outputs: 3x DisplayPort 2.1b, 1x HDMI 2.1b
- Dimensions: 290 x 120 x 50 mm (2-slot ATX), black color with RGB
- Recommended PSU: 750W
| CUDA | Yes |
| CUDA cores | 6144 |
| Graphics processor family | NVIDIA |
| Graphics processor | GeForce RTX 5070 |
| Processor frequency | 2587 MHz (boost) |
| Maximum resolution | 7680 x 4320 pixels |
| Maximum displays per videocard | 4 |
| Discrete graphics card memory | 12 GB |
| Graphics card memory type | GDDR7 |
| Memory bus | 192 bit |
| Memory clock speed | 28000 MHz (28 Gbps) |
| Interface type | PCI Express x16 5.0 |
| HDMI ports quantity | 1 |
| HDMI version | 2.1b |
| DisplayPorts quantity | 3 |
| DisplayPort version | 2.1b |
| TV tuner integrated | No |
| DirectX version | 12 Ultimate (12 API) |
| OpenGL version | 4.6 |
| Dual Link DVI | No |
| Overclocked (OC) edition | Yes |
| Cooling type | Active |
| Cooling technology | GIGABYTE WINDFORCE 3X |
| Number of fans | 3 fan(s) |
| Form factor | Full-Height/Full-Length (FH/FL) |
| Number of slots | 2 |
| Illumination | Yes (RGB) |
| Product colour | Black |
| Minimum system power supply | 750 W |
| Supplementary power connectors | 1x 16-pin |
| Length | 290 mm |
| Depth | 50 mm |
| Height | 120 mm |
| Package type | Box |
| Architecture | NVIDIA Blackwell |
| SFF-Ready | Yes |
