Seasonic FOCUS Gold SSR-750FM 750W Semi-Modular ATX PSU 80+ Gold (Boxed)
750W Seasonic FOCUS Gold SSR-750FM semi-modular ATX PSU with 80 PLUS Gold efficiency, quiet 120mm FDB fan, S2FC control, compact 140mm depth for reliable high-performance PC builds.
Please Note
The website is currently being actively developed, you are welcome to place the order and in 99% of the cases your order will be processed as usual, but in some cases there may be a delay or the price may change. We will notify you if there are any issues.
Discontinued
This item was discontinued and currently is not available for order on our website. The item may become available soon. Please contact us if you need more information regarding the upcoming arrivals.
| PSU (Power Supplies) - Wattage | 700 - 799 W |
|---|---|
| PSU (Power Supplies) - Efficiency Rating | 80 Plus Gold |
| PSU (Power Supplies) - Color | Black |
| PSU (Power Supplies) - Modularity | Semi-modular |
| PSU (Power Supplies) - PCIe GPU Connectors | 4x 8/6 pins |
| PSU (Power Supplies) - Length | Up to 140 mm |
| PSU (Power Supplies) - EPS CPU Connectors | 1x 4+4pin EPS/ATX12V |
The Seasonic FOCUS Gold SSR-750FM is a 750W semi-modular ATX power supply designed for reliable performance without premium pricing. It features 80 PLUS Gold certification for efficiency over 90% at typical loads, reducing energy waste and operating costs. The compact 140mm depth fits small ATX cases, while the 120mm Fluid Dynamic Bearing (FDB) fan with S2FC control ensures quiet, optimized cooling.
Key technologies include tight voltage regulation, DC-to-DC conversion for stable power delivery, and premium 105°C Japanese capacitors for longevity. Semi-modular cabling offers flexibility with essential cables fixed and peripherals detachable. It supports demanding systems with 744W on the +12V rail, 4x PCIe 6+2 pin connectors for GPUs, and full protections against over-voltage, power, heat, and shorts.
- 80 PLUS Gold certified efficiency
- Semi-modular design for clean builds
- 120mm FDB fan with hybrid control
- Compact 140mm depth
- 10-year warranty (confirmed via reviews)
- 4x PCIe (6+2 pin), 1x EPS (4+4 pin), 8x SATA
| Total power | 750 W |
| AC input voltage | 100 - 240 V |
| AC input frequency | 50 - 60 Hz |
| Input current | 5 - 10 A |
| Combined power (+3.3V) | 100 W |
| Combined power (+12V) | 744 W |
| Combined power (+5V) | 100 W |
| Combined power (-12V) | 3.6 W |
| Combined power (+5Vsb) | 15 W |
| Max output current (+3.3V) | 20 A |
| Max output current (+12V) | 62 A |
| Max output current (+5V) | 20 A |
| Max output current (-12V) | 0.3 A |
| Max output current (+5Vsb) | 3 A |
| Power protection features | Over power, Over voltage, Overcharge, Overheating, Short circuit, Under voltage |
| Motherboard power connector | 20+4 pin ATX |
| Motherboard power cable length | 61 cm |
| Number of SATA power connectors | 8 |
| Peripheral (Molex) power connectors (4-pin) | 3 |
| PCI Express power connectors (6+2 pin) | 4 |
| CPU power connector (4+4 pin) | Yes |
| CPU power cable length | 65 cm |
| ATX power connector (20+4 pin) | Yes |
| Floppy drive power connector | 1 |
| Floppy disk drive connector | Yes |
| Floppy disk drive cable length | 10.1 cm |
| Cabling type | Semi-Modular |
| 80 PLUS certification | 80 PLUS Gold |
| Purpose | PC |
| Power supply unit (PSU) form factor | ATX |
| Bearing technology | FDB |
| Mean time between failures (MTBF) | 100000 h |
| Product colour | Black |
| Cooling type | Active |
| Fan diameter | 12 cm |
| Number of fans | 1 fan(s) |
| Fan location | Top |
| On/off switch | Yes |
| Operating temperature (T-T) | 0 - 50 °C |
| Cables included | AC |
| Compliance certificates | RoHS |
| Certification | WEEE, ErP Lot 6, REACH |
| Safety | cTUVus, TUV, CB, CCC, BSMI, EAC, RCM |
| Width | 150 mm |
| Depth | 140 mm |
| Height | 86 mm |
| Warranty | 10 years |
